Démarreurs progressifs Schneider Altistart 1 ATS01N232LU

Description

The ATS01N232LU is a Soft Starter from the Altistart 01 range, engineered by Schneider Electric to ensure smooth starting and stopping for three-phase asynchronous motors. Designed for applications requiring a nominal current of 32 A, this unit operates with a supply voltage range of 200-240V and supports motor power ratings up to 7.5 kW. It effectively minimizes mechanical shock and current spikes, enhancing the operational longevity of connected industrial equipment.

Features

• Optimized for smooth acceleration and deceleration of motors
• Compact design for simplified panel integration
• Supports motor power ratings up to 7.5 kW
• Suitable for 200-240V supply voltage systems

Applications

• Small conveyor systems
• Industrial pumps and fans
• Packaging machinery
• General purpose motor-driven equipment

Technical Specifications

Installation Guidelines

• Mounting: The unit should be mounted in a vertical position to ensure proper convective cooling. Maintain required clearances as specified in the manual.
• Wiring: Ensure appropriate wire sizing to handle the 32 A current rating. Connect the motor and power supply lines according to the terminal markings provided on the housing.
• Environment: Install within an appropriate enclosure to protect the unit from dust, moisture, and extreme temperature fluctuations.
• Grounding: Connect the protective earth terminal to the system ground to ensure safety and EMI compliance.
