Schneider Modicon TSX Micro TSXDMZ28AR

Description

The TSXDMZ28AR is an I/O module from the Modicon TSX Micro range, manufactured by Schneider Electric. Designed to expand the capabilities of modular automation systems, this module features a robust configuration of 16 digital inputs (115 V AC) and 12 relay outputs.

Engineered for reliability in industrial control environments, the TSXDMZ28AR includes an integrated terminal block to simplify field wiring and commissioning. Despite its status as a phase-out product, it remains a critical component for the maintenance and support of legacy automation architectures that rely on the TSX Micro platform for high-performance machine control.

Features

• Modicon TSX Micro series I/O module
• Digital inputs: 16 (115 V AC)
• Digital outputs: 12 (Relay)
• Integrated terminal block for simplified wiring
• Compact, robust design for industrial panel integration
• Proven performance for demanding control tasks

Applications

• Legacy automation system expansion
• Industrial machine control and monitoring
• Process automation requiring AC input sensing
• Electrical control systems requiring relay-isolated outputs

Technical Specifications

Installation Guidelines

• Mounting: Install the module securely onto the TSX Micro rack/backplane. Ensure all retention clips or screws are engaged to maintain mechanical stability.
• Wiring: Connect field devices to the integrated terminal block following the specific terminal mapping for the TSXDMZ28AR. Use appropriate ferrules for stranded wires.
• Environment: Ensure the module is installed in a clean, ventilated control cabinet protected from extreme temperature fluctuations and conductive dust.
• Safety: Always isolate the control system power before installing or removing the module to prevent electrical hazards and damage to logic circuits.
• Verification: Perform a full I/O mapping verification and signal test within the configuration software after installation to ensure correct logic execution.
