Siemens 6ES7647-6BG20-0CB4 SIMATIC Box PC 627B

Il ne reste que 4 article(s) en stock

Fabricant : Siemens
N° de produit : 6ES7647-6BG20-0CB4
Pays d'origine :Allemagne
Type de produit : Industrial Box PC
Code-barres : 85371091
Paiement : Virement bancaire, Western Union
Poids : 7g
Dimensions : 120.50 x 50.50 x 10.00 cm
Port d'expédition : Xiamen
Garantie : 12 mois

Description

The Siemens 6ES7647-6BG20-0CB4 is a SIMATIC Box PC 627B, an industrial computing platform designed for robust automation applications. This unit features onboard graphics with 128 MB shared memory, dual 10/100/1000 Mbit/s Ethernet RJ45 ports, four USB V2.0 (high current) ports, and one serial (COM1) interface. An onboard RAID controller enhances data integrity, complemented by a front-side CompactFlash Drive No. 1 slot (without CF card). Integrated Watchdog, temperature, and fan monitoring ensure reliable operation. Powered by an Intel Core 2 Duo T7400 processor (2.16 GHz, 4 MB L2, 667 MHz FSB) and equipped with 1 GB DDR2 667 SODIMM RAM, it provides ample performance for industrial tasks. The system includes a 250 GB HDD SATA and two free PCI expansion slots. It operates on an AC 110/230V industrial power supply unit with NAMUR functionality and comes with a power supply cable for Europe. Pre-installed with Windows XP Professional Multi-language SP2 (EN, GER, FR, IT, SP), it also includes SIMATIC PC Image&Partition Creator V3.0 for system management.

Features

Onboard graphics with 128 MB shared memory
Dual 10/100/1000 Mbit/s Ethernet interfaces (RJ45)
Four USB V2.0 ports (high current)
One serial interface (COM1)
Onboard RAID controller
Front-side CompactFlash drive slot (without CF card)
Integrated Watchdog, temperature, and fan monitoring
Equipped with Intel Core 2 Duo T7400 processor (2.16 GHz, 4 MB L2, 667 MHz FSB)
1 GB DDR2 667 SODIMM RAM
AC 110/230V industrial power supply with NAMUR functionality
Two free PCI expansion slots
250 GB SATA Hard Disk Drive
Pre-installed Windows XP Professional Multi-language SP2 (EN, GER, FR, IT, SP)
Includes SIMATIC PC Image&Partition Creator V3.0

Applications

Industrial control systems
Data acquisition and processing
Human Machine Interface (HMI) stations
Manufacturing automation
Process visualization and monitoring

Technical Specifications

Manufacturer	Siemens
Range	Simatic Box PC
Subrange	PC627B
Product Type	PC box
Product Phase	Obsolete
Processor	Intel Core 2 Duo T7400 (2.16 GHz, 4 MB L2, 667 MHz FSB)
RAM	1 GB DDR2 667 SODIMM
Graphics	Onboard, 128 MB Shared memory
Ethernet	2x 10/100/1000 Mbit/s RJ45
USB Ports	4x V2.0 (high current)
Serial Port	1x (COM1)
Storage	250 GB HDD SATA, CompactFlash Drive No. 1 front-side (without CF)
RAID Controller	Onboard
Expansion Slots	2x PCI free
Power Supply	AC 110/230V industrial with NAMUR
Operating System	Windows XP Professional Multi-language SP2 (EN, GER, FR, IT, SP)
Included Software	SIMATIC PC Image&Partition Creator V3.0
Monitoring	Watchdog, temperature/fan monitoring
Package Dimensions (Calculated)	120.50 x 50.50 x 10.00 cm
Shipping Weight	7.00 kg
Commodity Code	85371091
Export Control Regulations (ECCN)	N

Key Features:

#Industrial Box PC #SIMATIC Box PC

What operating system is pre-installed on the Box PC?

The Siemens 6ES7647-6BG20-0CB4 comes with Windows XP Professional Multi-language SP2 (EN, GER, FR, IT, SP) pre-installed.

What type of power supply does this Box PC require?

It operates on an AC 110/230V industrial power supply unit with NAMUR functionality.

Does the Box PC support expansion cards?

Yes, it includes two free PCI expansion slots for additional functionality.

What is the purpose of the integrated Watchdog and monitoring features?

The integrated Watchdog, temperature, and fan monitoring features ensure system reliability and alert for potential operational issues, enhancing system uptime in industrial environments.

Is a CompactFlash card included with the unit?

The unit features a front-side CompactFlash Drive No. 1 slot, but the CF card itself is not included.
