Honeywell FC-SDOL-0424 Safety Manager Digital Output Module

Hanya 6 item tersisa di stok

Produsen: Honeywell
Nomor Produk: FC-SDOL-0424
Negara asal:Amerika Serikat
Jenis Produk: Safety Digital Output Modules
Pembayaran: T/T, Western Union
Berat: 2000g
Pelabuhan pengiriman: Xiamen
Garansi: 12 bulan

Description

To manage safety-critical field actuators within Honeywell Safety Manager environments, the FC-SDOL-0424 serves as a ruggedized fail-safe digital output module. This industrial component features four monitored output channels designed to drive 24 Vdc loads such as solenoid valves, indicators, and interposing relays up to 1 A per channel. Built-in short-circuit protection and overload detection mechanisms ensure high system availability and safety integrity in demanding industrial process control topologies. Each channel is monitored for line monitoring capabilities, allowing the safety controller to track field-side wiring integrity in real time.

Features

Four independent, short-circuit proof solid-state source output channels operating at 24 Vdc.
High-integrity diagnostic functions including overload detection and off-state leakage monitoring.
Internal fail-safe architecture designed for high-availability Safety Instrumented Systems (SIS).
Compact physical footprint conforming to standard Eurocard dimensions (4 HP width, 3U height).
Integrated watchdog (WDG) input verification to align output states with controller commands.

Applications

Emergency Shutdown Systems (ESD) in petrochemical plants.
Fire and Gas (F&G) mitigation control and alarming networks.
Burner Management Systems (BMS) in industrial boilers and power generation facilities.
Critical process safety interlocks in water treatment and chemical refineries.

Technical Specifications

Manufacturer	Honeywell
Part Number/Model	FC-SDOL-0424
Module Type	Digital Output Module (Fail-safe)
Number of Channels	4
Output Configuration	24 Vdc solid-state source (short-circuit proof)
Maximum Channel Current	1 A
Maximum Total Module Load	3.6 A (dissipation limit)
Maximum Load Inductance	0.5 H
Maximum Load Capacitance	1 uF
Overload Detection Threshold	Greater than 10 Ohm
Cold Lamp Resistance	Greater than 20 Ohm
Voltage Drop	Less than 1.3 V at 1 A
Off-state Leakage Current	Less than 0.1 mA
Current Sense Voltage Drop	Less than 1 V at 1 A
Watchdog (WDG) Input Current	4 mA
Power Requirements (5 Vdc)	15 mA
Power Requirements (24 Vdc Internal)	50 mA
Power Requirements (24 Vdc External)	15 mA (without output load)
Space Requirements	4 TE, 3 HE (4 HP, 3U rack space)
Shipping Weight	2 kg

Installation Guidelines

Mounting: Insert the module into an allocated slot within a compatible 3U Safety Manager rack, ensuring secure locking and alignment with backplane connectors.
Wiring: Field connection paths must use correctly rated wire gauges to handle continuous 1 A loads. Route low-voltage diagnostic lines separated from high-current AC power cables.
Cooling: Maintain clearance margins at the top and bottom of the subrack assembly to allow convective airflow, keeping operating temperatures within specifications.

Compliance and Certifications

CE
TUV (for safety instrumented functions up to SIL 3)
UL Listed
CSA Certified
FM Approved (Class I, Division 2 Hazardous Locations)

Key Features:

#Digital Output Modules #Safety Manager

What is the maximum output current capacity per channel for the FC-SDOL-0424?

Each of the 4 channels supports a maximum continuous current of 1 A, with a maximum module-wide load limit of 3.6 A due to thermal dissipation parameters.

Does the FC-SDOL-0424 digital output module support short-circuit protection?

Yes, the module is equipped with solid-state source outputs that are fully short-circuit proof and include overload detection thresholds.

Which safety systems is the FC-SDOL-0424 compatible with?

The module is designed for Honeywell Safety Manager systems and is certified by TUV for use in safety instrumented systems (SIS) up to SIL 3.
