8120E (8120 E) is an Enhanced Performance Main Chassis designed for Triconex Tricon safety instrumented systems. The chassis hosts main processors, communication modules, and triplicated I/O modules in Triple Modular Redundant architecture. It serves as the central hardware platform for high-integrity shutdown systems used in refineries, gas processing plants, and turbine protection systems.
The 8120E supports up to five I/O slot sets and integrates triplicated RS-485 expansion bus interfaces for deterministic communication with expansion chassis. The backplane implements TriBus, I/O bus, and communication bus to ensure fault-tolerant data exchange. Dual redundant power rails allow module replacement during operation, reducing downtime and enabling online maintenance. The chassis also supports high-performance communication modules and enhanced processors for SIL-rated safety applications.
The 8120E Enhanced Performance Main Chassis provides the structural and electrical backbone for Tricon systems. The chassis integrates:
Triplicated TriBus for processor synchronization and voting
Triplicated I/O bus for deterministic module communication
Dedicated communication bus for network modules
Dual redundant power rails with independent regulators
Offset keyed backplane connectors to prevent mis-insertion
Online module replacement capability without process interruption
The chassis hosts:
Main Processor modules (A, B, C channels)
Communication modules in COM slots
I/O module slot sets with hot-spare capability
Dual redundant power modules
Each logical slot supports active + hot spare module pairing, enabling automatic switchover when a fault occurs. The backplane distributes power across two independent rails to eliminate single-point failure.
| Parameter | Specification |
|---|---|
| Model | 8120E |
| Brand | Triconex |
| Product Type | Enhanced Performance Main Chassis |
| System Compatibility | Tricon v9 to v11 |
| Architecture | Triple Modular Redundant (TMR) |
| I/O Capacity | Up to 5 slot sets |
| Communication Bus | Triplicated RS-485 |
| Backplane Buses | TriBus, I/O Bus, Communication Bus |
| Power Configuration | Dual redundant power rails |
| Hot Swap | Supported |
| Expansion Support | Expansion chassis and RXM chassis |
| Operating Temp | 0 to 60 deg C |
| Mounting | Rack mounted |
| Dimensions | Approx 483 x 266 x 310 mm |
| Weight | Approx 6.5 kg |
| Origin | USA |
| Power Consumption | Depends on installed modules |
Is 8120E compatible with legacy Tricon processors?
Yes. The chassis supports multiple processor generations including Model 3006, 3007, 3008, and 3009 depending on system revision.
What is the difference between 8110 and 8120E chassis?
8120E provides enhanced communication capability, updated backplane architecture, and support for newer communication modules.
Can I replace modules without shutting down the system?
Yes. The TMR architecture allows online replacement. The controller automatically overrides the faulty channel.
How many expansion chassis can connect to 8120E?
A Tricon system supports up to 15 chassis including main, expansion, and RXM units.
Install dual power modules to maintain redundancy. Single power configuration reduces system availability.
Use shielded backplane cables for expansion connections. This prevents communication errors in high EMI environments.
Maintain proper chassis grounding. Connect the chassis earth point directly to cabinet ground bus.
The 8120E operates in harsh industrial environments and supports SIL-rated safety loops. The triplicated architecture eliminates single point failures.
Dual power rails and hot spare slots enable continuous operation during maintenance. This improves plant availability.
The chassis supports distributed I/O up to long distances using RXM modules. This simplifies large plant installations.
Backplane voting logic ensures deterministic control even during hardware faults. This makes it suitable for ESD and FGS systems.
Global Express Shipping
Returns & Warranty
Manufacturer: Triconex
Product No.: 8120E
Country of origin:United States
Product Type: Main Chassis
Payment: T/T, Western Union
Weight: 6500g
Dimensions: 483 x 266 x 310 mm
Shipping port: Xiamen
Warranty: 12 months
