Triconex 3481 / AO3481 Analog Output Module

SKU AO3481

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Triconex
  • Product No.: AO3481
  • Origin United States
  • Product Type: Analog Output Modules
  • Payment: T/T, Western Union
  • Weight: 1.1 kg
  • Dimensions: 30.5 cm x 7.6 cm x 26.7 cm
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

Analog Output Modules
Quantità
Call sales Contact

Product Description

Description

The Triconex 3481 (AO3481) is an analog output module designed for controlling analog field devices in Tricon safety-critical systems. Operating on a Triple Modular Redundant (TMR) architecture, the 3481 processes output data received over the system I/O bus from Main Processor modules and converts digital values into 4-20 mA analog output current signals. The module incorporates three independent execution channels to ensure fault tolerance and output voting before current delivery to connected final control elements.

Features

  • TMR architecture for high reliability in safety-critical control loops
  • 4-20 mA current loop output generation
  • Onboard diagnostic checking and status reporting via module indicators
  • Galvanic isolation between logic side and field control circuitry
  • Online hot-swappable installation without process interruption

Applications

  • Emergency Shutdown (ESD) systems
  • Fire and Gas (F&G) detection and control systems
  • Burner Management Systems (BMS)
  • Turbomachinery control and protection

Technical Specifications

Parameter Specification
Manufacturer Triconex / Invensys
Model 3481
Module Type Analog Output Module (AO3481)
Output Signal Range 4 to 20 mA
System Architecture Triple Modular Redundant (TMR)
Compatibility Tricon Main Chassis / I/O Expansion Chassis

Installation Guidelines

  • Chassis Slots: Insert the module into the designated analog output slot on the primary or expansion chassis backplane.
  • Hot Swap Procedure: When replacing an active module, ensure the secondary slot keying matches before inserting the replacement card.
  • Wiring: Connect field wiring to the corresponding external termination panel (ETP) screw terminals to prevent mechanical stress on module connectors.
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What output signal range does the module provide?
The module delivers standard 4 to 20 mA current loop output signals to field equipment.
Does the module support hot-swapping during operation?
The module supports online replacement without interrupting active process operations.
Which architecture is utilized for output execution?
The module utilizes a Triple Modular Redundant architecture across three isolated execution channels.
