The 991-06-50-01-00 is a thrust position transmitter designed for continuous shaft axial displacement monitoring in rotating machinery systems. It converts proximity probe signals into a proportional industrial output for integration with turbine supervisory instrumentation, machinery protection systems, and distributed control systems.
The transmitter supports thrust measurement applications in steam turbines, compressors, pumps, and other critical rotating assets where axial shaft movement monitoring is required. The unit is compatible with proximity probe systems using a 5.0 metre system length configuration and supports DIN-rail installation for industrial control panels.
Designed for machinery condition monitoring environments, the 991 Thrust Transmitter provides reliable signal conditioning and simplified integration into plant monitoring architectures.
| Model Code | Description |
|---|---|
| 991 | Thrust Transmitter |
| -06 | 0 to 0.6 mm full-scale option |
| -50 | 5.0 metres (16.4 feet) system length |
| -01 | 35 mm DIN-rail clips |
| -00 | Agency approval not required |
| Category | Specification |
|---|---|
| Manufacturer | Bently Nevada |
| Product Model | 991-06-50-01-00 |
| Product Type | Thrust Transmitter |
| Series | 991 |
| Measurement Range | 0 to 0.6 mm |
| System Length | 5.0 metres (16.4 feet) |
| Mounting Type | 35 mm DIN-rail clips |
| Agency Approval | Not required |
| Shipping Weight | 2.5 kg |
| Net Weight | 0.43 kg |
| Dimensions (H x W x D) | 53.3 mm x 73.9 mm x 100.1 mm |
| Body Height Without DIN Clip | 42.6 mm |
| Mounting Hole Distance (W x L) | 63.5 mm x 69.9 mm |
| Mounting Hole Diameter | 5.8 mm |
| Estimated Lead Time | 12 - 18 Weeks |
| Country of Origin | U.S.A |
What does the 991 transmitter measure?
It monitors axial shaft displacement in rotating machinery applications.
What is the full-scale measurement range?
The configured range is 0 to 0.6 mm.
Which mounting method is used?
The unit uses 35 mm DIN-rail clips.
What system length is supported by this model?
This version supports a 5.0 metre probe system length.
Can the transmitter be installed in control cabinets?
Yes. The compact housing is suitable for industrial panel installation.
Is this device suitable for turbine monitoring?
Yes. It is commonly used in turbine supervisory systems.
Does the unit include hazardous area approvals?
No approvals are specified for this configuration.
What industries commonly use this transmitter?
Power generation, oil and gas, and process industries frequently use it.
What type of machinery can use this transmitter?
Steam turbines, compressors, pumps, and other rotating assets.
Is the transmitter compatible with machinery protection systems?
Yes. It can interface with machinery monitoring and protection platforms.
