Designed as a side-mounted control interface accessory, the C9900-E517 push-button extension integrates directly with Beckhoff CP6xxx and CP7xxx Series Control Panels and Panel PCs. Optimized for 15-inch displays without integrated keyboards, this extension module expands operator capabilities by adding physical control elements to the right side of the display unit.
The C9900-E517 features 16 high-quality Siemens Signum square (30 x 30 mm) push-buttons with integrated signal lamps, along with a dedicated emergency stop switch. To ensure flexible integration into existing automation networks, the module supports dual-channel command transmission. Primary normally-open (NO) contacts and all signal lamps are transmitted digitally via CP-Link or USB. For safety-critical or hardwired requirements, a secondary normally-open contact for each push-button and the emergency stop key can be wired directly via an integrated terminal row.
| Beckhoff Automation |
| C9900-E517 |
| 15-inch CP6xxx and CP7xxx series without keyboard (e.g., CP6x31-00xx, CP7x31-00xx) |
| Right side |
| Siemens Signum square, 30 x 30 mm (16 units) |
| 1x Siemens Signum, directly wireable |
| Integrated signal lamps for all 16 push-buttons |
| CP-Link or USB (for lamps and primary NO contacts) |
| Terminal row for secondary NO contacts |
| 5.0 kg |
| Interface Type | Function / Routing |
|---|---|
| Transmits status of all 16 primary normally-open (NO) contacts and controls the 16 signal lamps. | |
| Provides individual direct wire access for the secondary normally-open (NO) contacts of each push-button. | |
| Direct connection points for hardwiring the emergency stop switch into safety relays or fail-safe PLC modules. |
Global Express Shipping
Returns & Warranty
Manufacturer: BECKHOFF
Product No.: C9900-E517
Country of origin:Germany
Product Type: Control Panel Accessories
Payment: T/T, Western Union
Weight: 5000g
Dimensions: drawings with dimensions of the push-button e x tensions as AutoCAD DXF file
Shipping port: Xiamen
Warranty: 12 months
