C9900-E577

BECKHOFF

BECKHOFF C9900-E577 Push-Button Extension

SKU C9900-E577

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: BECKHOFF
  • Product No.: C9900-E577
  • Origin Germany
  • Product Type: Control Panel Accessories
  • Payment: T/T, Western Union
  • Weight: 5.0 kg
  • Dimensions: 40 x 20 x 10 cm
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

BECKHOFF C9900 Control Panel Accessories
Quantità
Call sales Contact

Product Description

Description

The BECKHOFF C9900-E577 is a push-button extension designed specifically for integration with CP6xxx and CP7xxx Control Panels and Panel PCs featuring a 15-inch display and an alphanumeric keyboard. This hardware accessory expands operator control capabilities directly at the machine interface, providing dedicated physical push-buttons and an emergency stop function adjacent to the industrial display unit.

Positioned on the right side of compatible control panels, this unit features 18 square push-button keys equipped with integrated signal lamps and customizable key labels for individual marking. Signal transmission and lamp control are handled via CP-Link or USB, while dual-contact wiring options support flexible integration into machine safety and control architectures.

Features

  • Designed for mounting on the right side of CP6x32-00xx and CP7x32-00xx Control Panels and Panel PCs
  • Equipped with 18 square push-button keys featuring integrated signal lamps
  • Includes one directly wireable emergency stop key
  • Individual marking capability via replaceable push-button cap labels
  • Push-button states transmitted via CP-Link or USB with one normally-open contact
  • Direct wiring support for a second normally-open contact on all push-buttons via an internal terminal row
  • Signal lamps driven exclusively via CP-Link or USB communication

Applications

  • Machine tool control panels and operator terminals
  • Industrial automation systems requiring hardwired emergency stop integration
  • HMI operator stations utilizing BECKHOFF CP6xxx and CP7xxx series hardware
  • Process visualization environments requiring tactile operator override controls

Technical Specifications

General

Parameter Specification
Manufacturer BECKHOFF
Exact Model C9900-E577
Product Type Push-button extension
Compatibility CP6xxx and CP7xxx Control Panels and Panel PCs with 15-inch display and alphanumeric keyboard (CP6x32-00xx, CP7x32-00xx)
Mounting Position Right side
Country of Origin Germany

Operator Controls and Signaling

Parameter Specification
Push-Button Keys 18 keys with signal lamp, type Siemens Signum square, 30 x 30 mm
Emergency Stop 1 key, type Siemens Signum, directly wireable
Key Labeling Customizable labels for push-button caps
Contact Configuration (Bus) 1 normally-open contact per push-button transmitted via CP-Link or USB
Contact Configuration (Direct) Second normally-open contact per push-button directly wireable via terminal row
Signal Lamp Control Transmitted via CP-Link or USB

Installation Guidelines

  1. Ensure the host BECKHOFF Control Panel or Panel PC is completely de-energized and disconnected from power supplies before beginning mechanical installation.
  2. Verify that the mounting location on the right side of the 15-inch control panel with alphanumeric keyboard matches the C9900-E577 specification.
  3. Attach the push-button extension securely to the panel enclosure using the designated mechanical mounting points.
  4. Connect the signal transmission lines via CP-Link or USB according to the control panel system manual.
  5. Wire the emergency stop key and secondary push-button normally-open contacts to the internal terminal row where direct hardwired signals are required.
  6. Insert custom labels into the push-button caps as needed for operator identification.
  7. Restore power to the system and verify communication, emergency stop functionality, and signal lamp operation through the connected control panel.
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
Quali pannelli di controllo sono compatibili con il BECKHOFF C9900-E577?
Il BECKHOFF C9900-E577 è progettato per i pannelli di controllo e i Panel PC CP6xxx e CP7xxx con display da 15 pollici e tastiera alfanumerica, in particolare per modelli come CP6x32-00xx e CP7x32-00xx.
Dove viene montato il BECKHOFF C9900-E577 sul pannello?
Il BECKHOFF C9900-E577 si monta direttamente sul lato destro del pannello di controllo o Panel PC compatibile da 15 pollici.
Come vengono trasmessi i segnali dei pulsanti sul BECKHOFF C9900-E577?
Il BECKHOFF C9900-E577 trasmette gli stati dei pulsanti tramite CP-Link o USB utilizzando un contatto normalmente aperto e dispone inoltre di un secondo contatto normalmente aperto, cablabile direttamente tramite una morsettiera interna.
Il BECKHOFF C9900-E577 include un pulsante di arresto di emergenza?
Sì, il BECKHOFF C9900-E577 include un pulsante di arresto di emergenza Siemens Signum, collegabile direttamente al circuito di sicurezza della macchina.
Come vengono controllate le spie sul BECKHOFF C9900-E577?
Le spie sul BECKHOFF C9900-E577 vengono controllate e trasmesse esclusivamente tramite connessione CP-Link o USB.
