BECKHOFF C9900-E784 Control Panel Push-Button Extension

SKU C9900-E784

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: BECKHOFF
  • Product No.: C9900-E784
  • Origin Germany
  • Product Type: Push-button extension
  • Payment: T/T, Western Union
  • Weight: 3.5 kg
  • Dimensions: 80 mm x 400 mm x 120 mm (H x W x D)
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

Control Panel Accessories Push-button Extensions
Quantità
Call sales Contact

Product Description

Description

The BECKHOFF C9900-E784 is a PLC push-button extension designed for installation below 15-inch display Control Panels and Panel PCs without keyboards, including CP6942, CP7942, CP6242, CP6442, CP6542, and CP7242. Built primarily for machine tool operator interfaces, the C9900-E784 integrates 16 push-button keys with signal lamps, a directly wireable emergency stop key, a 23-position graycode switch, and a front-accessible 2-port USB A interface protected by IP65 screw caps. All push-buttons and indicator lights communicate via USB, with push-buttons offering an additional directly wireable contact via a terminal row for hardware integration.

Features

  • Integrated push-button extension mounted below 15-inch control units
  • 16 push-button keys (30 x 30 mm, Siemens Signum square) with signal lamps and customizable cap labels
  • 1 emergency stop key (Siemens Signum) for direct hardwired safety circuits
  • Dual contact paths per push-button: one normally-open contact via USB and one additional normally-open contact directly wireable via terminal row
  • USB-controlled indicator lights and 23-position graycode switch
  • Front panel equipped with 2-port USB A interface featuring IP65 screw caps

Applications

  • Machine tool control panels and CNC operator interfaces
  • Industrial automation operator panels requiring manual control inputs
  • Industrial PC extensions for CP6xxx and CP7xxx series Panel PCs

Technical Specifications

Specification Value
Manufacturer BECKHOFF
Model C9900-E784
Compatible Hardware CP6942, CP7942, CP6242, CP6442, CP6542, CP7242 (15-inch display without keyboard)
Push-Button Keys 16 keys, 30 x 30 mm, Siemens Signum square, with signal lamp
Push-Button Contacts 1 NO contact via USB; 1 NO contact directly wireable via terminal row
Emergency Stop Key 1 key, Siemens Signum, directly wireable
Selector Switch 1 graycode switch with 23 positions, controlled via USB
Indicator Lights Control Controlled exclusively via USB
Front Interface 2-port USB A interface with IP65 screw cap
Shipping Weight 5 kg

Installation Guidelines

  • Panel Integration: Mount the push-button extension directly below the supported 15-inch CP6xxx or CP7xxx series Control Panel or Panel PC.
  • USB Wiring: Connect the internal USB communication line to the host Control Panel / Panel PC for push-button signaling, indicator light control, and graycode switch data.
  • Terminal Row Wiring: Route hardwired secondary normally-open contact lines from the terminal row directly to the PLC or safety control circuits.
  • Emergency Stop Wiring: Connect the emergency stop key directly into the machine's safety circuit according to local safety regulations.
  • Front USB Protection: Ensure the front USB screw caps are fully tightened when not in use to maintain IP65 protection against dust and liquids.
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
Which panel models are compatible with this push-button extension?
The device is compatible with BECKHOFF CP6942, CP7942, CP6242, CP6442, CP6542, and CP7242 Control Panels and Panel PCs featuring a 15-inch display without a keyboard.
How are the push-button signals transmitted to the controller?
All push-buttons transmit one normally-open contact via USB, and additionally offer a second normally-open contact that can be directly wired via a terminal row.
How is the emergency stop button wired?
The emergency stop key is directly wireable into the control system safety circuit.
What protection level is provided for the front USB ports?
The front 2-port USB A interface provides IP65 protection when the screw caps are properly closed.
