CP2719-0020

BECKHOFF

BECKHOFF CP2719-0020 CP27xx Fanless Multi-Touch Built-in Panel PC

SKU CP2719-0020

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: BECKHOFF
  • Product No.: CP2719-0020
  • Origin Germany
  • Product Type: Built-in Panel PCs
  • Payment: T/T, Western Union
  • Weight: 5.0 kg
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

Built-in Panel PCs CP27xx HMI
Quantità
Call sales Contact

Product Description

Description

Engineered for high-performance industrial control and visualization, the Beckhoff CP2719-0020 fanless multi-touch built-in Panel PC delivers dependable HMI functionality in demanding environments. This robust industrial computer features a integrated 19-inch display with a resolution of 1280 x 1024, housed in a durable aluminum casing with a premium glass front. Its high-durability construction and fanless cooling system make it ideal for control cabinet installations across modern manufacturing facilities.

The core design of the CP2719-0020 centers on an Intel Atom processor, allowing efficient handling of TwinCAT PLC, HMI, and motion control tasks. Multi-finger touch capability provides intuitive user interaction, while dual CFast storage slots allow for secure, vibration-resistant operating system and data storage. Installation is simplified through integrated pull-out clamping levers, facilitating fast mounting without the risk of loose mechanical parts.

Features

  • Multi-Touch Technology: Supports multi-finger interaction via a hardened glass front panel.
  • Fanless Reliability: Passive cooling architecture with no moving parts, increasing system uptime and reducing maintenance requirements.
  • Flexible Storage Options: Dual CFast slots enable reliable, high-speed solid-state storage configurations.
  • Rugged Protection: Rated IP65 on the front panel and IP20 on the rear, suitable for challenging environments.
  • Convenient Mounting: Integrated pull-out clamping levers for fast, tool-secure cabinet installation.
  • Onboard Connectivity: Standard dual gigabit Ethernet ports alongside USB 3.0, USB 2.0, and DVI interfaces.

Applications

  • Machine tool and manufacturing line visualization.
  • Automated process monitoring and control systems.
  • Oil & Gas, energy production, and water treatment plants.
  • Material handling and packaging machine automation.

Technical Specifications

Manufacturer BECKHOFF
Part Number / Model CP2719-0020
Device Type Fanless Multi-Touch Built-In Panel PC
Display Size 19-inch
Resolution 1280 x 1024
Processor Intel Atom x5-E3930 (1.3 GHz, 2 cores) or Intel Atom x5-E3940 (1.6 GHz, 4 cores)
Memory 4 GB DDR4 RAM (expandable up to 8 GB ex factory)
Storage Slots 2 x CFast slots (supports 40 GB to 320 GB CFast)
Onboard Ethernet 2 x 100/1000BASE-T ports (option for 1 additional)
Interfaces 2 x USB 3.0, 2 x USB 2.0, 1 x DVI, 1 x USB (front side)
PCIe Expansion 1 x PCIe module slot (optional)
Housing Material Aluminum housing with glass front
Power Supply 24 V DC (optional UPS integration)
Protection Rating IP65 (front), IP20 (rear)
Operating Temperature 0 to 55 degC
Shipping Weight 5.0 kg

Installation Guidelines

  • Panel Mounting: Insert the device into the prepared control cabinet cutout. Secure using the integrated pull-out clamping levers. Ensure the seal is flush with the mounting surface to maintain IP65 protection on the front.
  • Thermal Clearance: Maintain at least 50 mm clearance above and below the device to allow proper convective cooling, as the device is completely fanless.
  • Grounding and Shielding: Connect the ground terminal on the chassis directly to the central grounding point of the control cabinet. Use shielded cables for all network connections.
  • Power Connection: Provide a stable 24 V DC power source. Ensure all wiring is completed while the primary power supply is switched off.

Compliance and Certifications

  • CE
  • UL Listed (US and Canada)
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What is the display size and resolution of the Beckhoff CP2719-0020?
The CP2719-0020 features a 19-inch display with a resolution of 1280 x 1024 pixels.
Is the CP2719-0020 Panel PC cooled by internal fans?
No, the CP2719-0020 is a fanless design that utilizes passive cooling through its aluminum housing to ensure maintenance-free operation.
What type of storage is used in the CP2719-0020?
The Panel PC includes two slots for high-speed, vibration-resistant CFast cards, supporting storage capacities from 40 GB up to 320 GB.
What protection rating does the front display offer?
The front side of the CP2719-0020 features an IP65 protection rating when correctly installed in a panel cutout, safeguarding it against dust and water jets. The rear side is rated IP20.
What is the operating temperature range for this Panel PC?
The CP2719-0020 operates reliably in ambient temperatures ranging from 0 to 55 degC.
