Designed for highly accurate temperature measurement in demanding industrial automation applications, the Beckhoff EL3201-0020 is a high-precision 1-channel analog input terminal configured for Resistance Temperature Detectors (RTD). This EtherCAT terminal enables direct connection of sensors utilizing 4-wire connection technology to ensure maximum measurement accuracy by compensating for cable resistance. Each module is factory-calibrated and delivered with a corresponding calibration certificate, making it suitable for applications requiring strict compliance and traceably accurate temperature logs.
The EL3201-0020 processes signals from various RTD sensor types, including Pt and Ni variants, as well as general resistance measurements. Its integration into the EtherCAT system allows for fast, deterministic communication with the central controller, translating process data directly into a 1 x 32-bit RTD process image. Features such as integrated digital filtering and configurable limit value monitoring allow for flexible adaptation to specific process dynamics.
| Beckhoff |
| EL3201-0020 |
| EtherCAT Terminal, 1-Channel Analog Input |
| 4-wire connection |
| Temperature / RTD |
| Pt100, Pt200, Pt500, Pt1000, Ni100, Ni120, Ni1000, resistance measurement (e.g., potentiometer 10 Ohm to 1.25 kOhm), KTY sensors |
| -200 to +850 degC |
| -60 to +250 degC |
| -200 to +320 degC |
| 0.01 degC per digit |
| approx. 24 ms default (4 to 500 ms configurable) |
| Less than 0.5 mA (load-dependent) |
| Less than +/-0.1 degC at 40 degC ambient temperature (4-wire, Pt100 sensor, -200 to +320 degC, 50 Hz filter) |
| Factory-calibrated |
| 500 V (E-bus / signal voltage) |
| typ. 190 mA |
| 1 x 32 bit RTD input |
| 12 mm x 100 mm x 68 mm |
| approx. 60 g |
| 0 to +55 degC |
| -25 to +85 degC |
| 95 %, non-condensing |
| Conforms to EN 61000-6-2 / EN 61000-6-4 |
| Conforms to EN 60068-2-6 / EN 60068-2-27 |
| IP20 / variable |
