BECKHOFF ELX9410 Power Supply Terminal for E-bus Refresh

SKU ELX9410

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: BECKHOFF
  • Product No.: ELX9410
  • Origin Germany
  • Product Type: Power Supply Terminals
  • Payment: T/T, Western Union
  • Weight: 0.5 kg
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

EtherCAT Terminals Power Supply Terminals
Quantità
Call sales Contact

Product Description

Description

The ELX9410 is a specialized power supply terminal engineered for E-bus refresh in Beckhoff ELX and EL series terminal systems. This module provides a regulated 5 V DC supply to the E-bus, ensuring stable power delivery in terminal configurations where the primary supply may be insufficient due to high load or long terminal strings. The ELX9410 is designed for hazardous environments, featuring comprehensive ATEX, IECEx, and cFMus certifications for use in potentially explosive atmospheres (Zone 2/Division 2). It includes integrated diagnostics in the process image, allowing controllers to monitor terminal power status in real-time. The unit is fully short-circuit proof and maintains high reliability within a compact 12 mm housing width.

Features

  • E-bus refresh functionality for ELX and EL terminal series
  • 5 V DC output for stable E-bus supply (up to 1 A)
  • Integrated diagnostic feedback via process image
  • Short-circuit proof design for enhanced safety
  • Compact 12 mm housing
  • Wide operating temperature range: -25 to +60 Celsius
  • Suitable for hazardous areas (ATEX, IECEx, cFMus rated)

Applications

  • Powering extensive EtherCAT I/O segments in hazardous locations
  • Maintaining E-bus voltage levels in complex control systems
  • Industrial automation requiring robust, certified power distribution
  • Decentralized I/O nodes in oil, gas, or chemical process environments

Technical Specifications

Feature Specification
Manufacturer BECKHOFF
Part Number ELX9410
Input Voltage 24 V DC
Output Voltage 5 V DC
Max. Output Current 1 A
Housing Width 12 mm
Operating Temperature -25 to +60 Celsius
Storage Temperature -40 to +85 Celsius
Protection Rating IP20
Weight approx. 65 g
Shipping Weight 2 kg

Installation Guidelines

  • Mounting: Snap the ELX9410 onto the DIN rail as part of your EtherCAT terminal segment.
  • Placement: Position the module at points in the terminal string where E-bus power consumption approaches the specified limits of the coupler or previous power supply.
  • Diagnostics: Configure the host controller to read the diagnostic bits from the process image to receive immediate notification of voltage drops or short-circuit events.
  • Hazardous Area Precautions: Ensure all installation practices conform to local safety standards for Class I, Division 2 or Zone 2 environments (e.g., proper sealing and non-incendive wiring practices).

Compliance and Certifications

  • CE, UL
  • ATEX: II 3 G Ex ec IIC T4 Gc
  • IECEx: Ex ec IIC T4 Gc
  • cFMus: Class I, Division 2, Groups A, B, C, D; Class I, Zone 2, AEx ec IIC T4 Gc
  • CCC
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What is the main purpose of the ELX9410?
The ELX9410 is used to refresh the E-bus power supply for EL and ELX series terminals, ensuring sufficient voltage is available for downstream I/O modules.
Can the ELX9410 be used in hazardous locations?
Yes, it is certified for hazardous areas with ATEX, IECEx, and cFMus ratings, specifically for use in Zone 2 or Class I, Division 2 environments.
What diagnostic information is provided?
The terminal provides diagnostic data directly into the process image, allowing the controller to monitor the health and status of the E-bus supply.
What is the maximum output current of this terminal?
The ELX9410 provides a maximum output current of 1 A for the E-bus supply.
