BECKHOFF EPP9001-0060 EtherCAT P/EtherCAT Connector

SKU EPP9001-0060

Disponibile

12-month warranty
Free returns within 30 days

Manufacturer: BECKHOFF
Product No.: EPP9001-0060
Origin Germany
Product Type: EtherCAT P/EtherCAT connector
Payment: T/T, Western Union
Weight: 0.5 kg
Dimensions: 30 mm x 86 mm x 22 mm
Shipping port: Xiamen
Warranty: 12 months

Product Description

Description

The EPP9001-0060 is a specialized EtherCAT P to EtherCAT converter designed to bridge EtherCAT P infrastructure with standard EtherCAT devices. This module functions as an interface bridge that separates the combined data and power lines of EtherCAT P into an EtherCAT data stream and a dedicated 24 V DC power feed. Housed in a robust, IP65/66/67-rated PA6 (polyamide) casing, this EtherCAT connector is ideal for decentralized machine-mounting environments where power distribution and data communication need to be split for legacy or non-P EtherCAT hardware.

Features

EtherCAT P to EtherCAT converter functionality
Integrated power decoupling (separates 24 V DC power from EtherCAT P stream)
Robust M8 shielded, screw-type connection interfaces
IP65/66/67 protection rating for harsh industrial environments
Compact form factor (30 mm x 86 mm x 22 mm)
Reliable operation from -25 to +60 Celsius
Simplified integration for mixed EtherCAT P and standard EtherCAT topologies

Technical Specifications

Feature	Specification
Manufacturer	BECKHOFF
Part Number	EPP9001-0060
Protocol	EtherCAT P/EtherCAT
Bus Interface	1 x M8 P-coded (IN), 1 x M8 (OUT)
Nominal Voltage	24 V DC (-15 %/+20 %)
Total Current	max. 3 A per US and UP
Protection Rating	IP65/66/67
Weight	approx. 90 g
Dimensions (W x H x D)	30 mm x 86 mm x 22 mm
Shipping Weight	2 kg

Installation Guidelines

Mounting: Use the two 3.5 mm diameter fixing holes with M3 screws to mount the module onto the machine frame. The variable installation position allows for optimal cable routing.
Connections: The EtherCAT P input uses a P-coded M8 socket, while the EtherCAT output uses a standard M8 socket. Ensure cables are fully seated and screwed tight to maintain IP67 sealing.
Power Management: Note that the module supports a maximum feed-in of 3 A per US (System Power) and UP (Peripheral Power). Ensure the power budget of downstream devices does not exceed these values.
Grounding: As the module is shielded, ensure the mounting surface provides a good electrical connection to ground, or utilize the shield path through the M8 connectors to mitigate electromagnetic noise.

Shipping & Returns

Global Express Shipping

Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
12-Month Warranty: Every industrial component is backed by our technical warranty.

FAQ

What is the primary role of the EPP9001-0060?

It serves as a converter that splits the combined EtherCAT P signal (data + power) into a standard EtherCAT data stream and a 24 V DC power feed for standard EtherCAT devices.

Does this module require a separate power supply?

No, it receives power from the EtherCAT P line (US and UP) and distributes it to the output, up to a maximum of 3 A.

Can this be used in environments with dust or water spray?

Yes, with an IP65/66/67 rating, it is protected against dust ingress and high-pressure water jets, making it suitable for wet or dirty industrial environments.
