ERI2008-0002

BECKHOFF

BECKHOFF ERI2008-0002 IO-Link Box

SKU ERI2008-0002

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: BECKHOFF
  • Product No.: ERI2008-0002
  • Origin Germany
  • Product Type: IO-Link Boxes
  • Payment: T/T, Western Union
  • Weight: 0.265 kg
  • Dimensions: 30 mm x 126 mm x 26.5 mm
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

ERI Series IO-Link Boxes
Quantità
Call sales Contact

Product Description

Description

The BECKHOFF ERI2008-0002 is a ruggedized IO-Link box module designed to provide decentralized digital output capabilities in demanding industrial environments. Equipped with eight digital outputs, this device operates as an IO-Link device under the Class B specification, facilitating both control data and auxiliary power transmission over a single connection interface.

Housed in a robust zinc die-cast enclosure, the BECKHOFF ERI2008-0002 provides superior mechanical stability and resistance compared to standard plastic alternatives. It connects to the higher-level IO-Link master via an A-coded M12 connector, while field-level actuators connect directly through space-saving M8 screw-type connection points. This architecture simplifies field installation, reduces cabling requirements, and eliminates the need for protective control cabinets near the machine footprint.

Features

  • Eight digital output channels supporting up to 0.5 A per channel from the auxiliary power contact.
  • Rugged zinc die-cast housing engineered for extreme mechanical resistance in heavy-use environments.
  • High IP65, IP66, and IP67 protection ratings, ensuring dust-tight performance and water immersion resistance.
  • IO-Link V1.1 Class B specification compliance with COM 3 transmission rates up to 230.4 kbaud.
  • Individually short-circuit proof output channels with built-in diagnostic and protection capabilities.
  • Complete electrical isolation between the L+ logic supply and the P24 auxiliary load supply.

Applications

  • Decentralized actuator control in machine building and automated assembly lines.
  • Applications requiring robust field bus distribution without the use of centralized terminal boxes.
  • Heavy-duty mechanical handling and conveyor systems exposed to vibration, moisture, or particulate matter.
  • Integration with pneumatic valves, contactors, indicators, and small DC motors.

Technical Specifications

General

Parameter Specification
Manufacturer BECKHOFF
Exact Model ERI2008-0002
Product Type IO-Link Box
Housing Material Zinc die-cast
Protection Rating IP65, IP66, IP67 (conforms to EN 60529)
Installation Position Variable (2 fixing holes, 3.5 mm diameter for M3 screws)

IO-Link and Communication

Parameter Specification
Protocol IO-Link
Specification Version IO-Link V1.1, Class B
Data Transfer Rates 230.4 kbaud (COM 3)
Interface Connection 1 x M12 plug, A-coded

Electrical and Outputs

Parameter Specification
Number of Outputs 8 digital outputs
Output Connections M8, screw-type connection
Load Type Ohmic, inductive, lamp load
Nominal Output Voltage 24 V DC (-15% / +20%)
Max. Output Current 0.5 A per channel (from P24, individually short-circuit proof)
Short-Circuit Current Typical 1.5 A
Current Consumption (Logic) Typical 100 mA from L+
Auxiliary Power Current Typical 20 mA + load
Electrical Isolation L+ / P24: Yes

Physical and Environmental

Parameter Specification
Dimensions (W x H x D) 30 mm x 126 mm x 26.5 mm
Weight Approx. 265 g
Operating Temperature -25 degC to +60 degC
Storage Temperature -40 degC to +85 degC
Vibration/Shock Resistance Conforms to EN 60068-2-6 / EN 60068-2-27
EMC Immunity/Emission Conforms to EN 61000-6-2 / EN 61000-6-4
Approvals/Markings CE, UL

Connections / Interfaces

Interface or Terminal Function
IO-Link Interface (M12) 1 x M12 plug, A-coded (Class B power and communication connection)
Digital Outputs (M8) 8 x M8 sockets, 3-pin (connection of actuators and field devices)

Installation Guidelines

  1. Verify that the supply voltage matches the nominal range of 24 V DC (-15% / +20%) before connecting any cables.
  2. De-energize all electrical supplies to the system prior to mounting or wiring the IO-Link box.
  3. Securely mount the module directly to the machine frame using two 3.5 mm diameter fixing holes designed for M3 screws. Do not overtighten.
  4. Connect the IO-Link Class B cable to the A-coded M12 plug interface, ensuring the connection is threaded tightly to maintain the specified IP protection level.
  5. Attach the actuator wiring to the M8 screw-type ports. Unused M8 or M12 connections must be sealed with appropriate protective caps to preserve IP65/66/67 integrity.
  6. Verify correct operation through the host controller software configuration, monitoring current draw and checking for short-circuit faults.
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What is the primary function of the BECKHOFF ERI2008-0002?
The BECKHOFF ERI2008-0002 is a decentralized IO-Link box module equipped with 8 digital outputs (24 V DC, 0.5 A) housed in a durable, zinc die-cast casing to control field actuators directly in harsh environments.
What connection technology does the BECKHOFF ERI2008-0002 use for I/O and communication?
The BECKHOFF ERI2008-0002 features 8 x M8 screw-type connections for its digital outputs and a single A-coded M12 plug for the IO-Link host communication interface.
What IO-Link specification and class does the BECKHOFF ERI2008-0002 support?
The BECKHOFF ERI2008-0002 complies with the IO-Link V1.1 Class B specification and supports COM 3 data transfer rates up to 230.4 kbaud.
How is the BECKHOFF ERI2008-0002 protected against environmental elements?
The BECKHOFF ERI2008-0002 features a robust die-cast zinc housing with an IP65, IP66, and IP67 protection rating, making it highly resistant to dust, high-pressure water jets, and temporary immersion.
Does the BECKHOFF ERI2008-0002 offer channel-level safety or isolation?
Yes, the BECKHOFF ERI2008-0002 provides electrical isolation between the L+ logic supply and the P24 auxiliary load supply, and each of its 8 digital outputs is individually short-circuit proof.
