BECKHOFF IP1002-B310 Fieldbus Box

SKU IP1002-B310

Disponibile

12-month warranty
Free returns within 30 days

Manufacturer: BECKHOFF
Product No.: IP1002-B310
Origin Germany
Product Type: Fieldbus Boxes
Payment: T/T, Western Union
Weight: 0.35 kg
Dimensions: 3.0 x 17.5 x 2.65 cm
Shipping port: Xiamen
Warranty: 12 months

Product Description

Description

The BECKHOFF IP1002-B310 is a decentralized Fieldbus Box featuring an integrated PROFIBUS interface and 8 digital inputs. Designed for machine-level installation without a control cabinet, this IP65/66/67-rated module connects binary control signals directly to a PROFIBUS DP network in harsh industrial environments.

Equipped with M12 connectors for signal acquisition and M8 connectors for power distribution, the IP1002-B310 integrates into automated systems requiring distributed signal collection. Configuration is supported via the KS2000 software or the controller utilizing DP-V1 extensions, with automatic baud rate detection up to 12 Mbaud.

Features

8-channel digital input configuration conforming to EN 61131-2, type 2
Integrated PROFIBUS DP interface with automatic baud rate detection up to 12 Mbaud
M12 connection technology for secure sensor wiring
M8 connectors for 24 V DC power feed and downstream connection
Rugged PA6 polyamide housing with IP65/66/67 protection rating for cabinet-free installation
DP-V1 extension support for flexible parameterization and diagnostics

Applications

Decentralized machine building and factory automation
Conveyor and material handling systems
Assembly lines and packaging machinery
Industrial environments requiring cabinet-free I/O distribution

Technical Specifications

General

Parameter	Specification
Manufacturer	BECKHOFF
Exact Model	IP1002-B310
Product Type	Fieldbus Box
Housing Type	Standard housing
Material	PA6 (polyamide)
Dimensions (W x H x D)	30 mm x 175 mm x 26.5 mm
Installation Position	Variable
Mounting	2 fixing holes 3.5 mm diameter for M3
Country of Origin	Germany

Digital Inputs

Parameter	Specification
Number of Inputs	8
Input Connections	M12, screw type
Nominal Input Voltage	24 V DC (-15 %/+20 %)
Input Filter	3.0 ms
"0" Signal Voltage	-3 to +5 V (EN 61131-2, type 2)
"1" Signal Voltage	11 to 30 V (EN 61131-2, type 2)
Input Current	typ. 6 mA (EN 61131-2, type 2)
Sensor Supply	from control voltage, max. 0.5 A, short-circuit proof in total
Bit Width in Process Image	8 inputs

Communication and PROFIBUS Interface

Parameter	Specification
Bus System	PROFIBUS DP
Bus Interface	1 x M12 socket, 5-pin, B-coded
Data Transfer Rates	Automatic detection up to 12 Mbaud
Configuration	Via KS2000 or controller, DP-V1 extensions supported

Electrical

Parameter	Specification
Control Voltage Supply	24 V DC (-15 %/+20 %)
Power Supply Connection	Feed: 1 x M8 male socket, 4-pin; Downstream: 1 x M8 female socket, 4-pin
Box Supply Current	85 mA + current consumption of sensors, max. 0.5 A
Electrical Isolation	Control voltage/fieldbus: no; control voltage/inputs: according to I/O type

Environmental and Approvals

Parameter	Specification
Operating Temperature Range	0 to +55 degC
Storage Temperature Range	-25 to +85 degC
Vibration / Shock Resistance	Conforms to EN 60068-2-6 / EN 60068-2-27
EMC Immunity / Emission	Conforms to EN 61000-6-2 / EN 61000-6-4
Protection Class	IP65 / IP66 / IP67 (conforms to EN 60529)
Approvals / Markings	CE, UL

Connections / Interfaces

Interface / Terminal	Function
M12 Socket (5-pin, B-coded)	PROFIBUS DP bus interface
M12 Sockets (Screw type)	8 x Digital inputs (channels 1 to 8)
M8 Male Socket (4-pin)	Control voltage power feed (24 V DC)
M8 Female Socket (4-pin)	Downstream control voltage power connection

Installation Guidelines

Ensure the system is completely de-energized before mounting or wiring the BECKHOFF IP1002-B310.
Secure the unit directly onto a flat mounting surface using two M3 screws through the 3.5 mm fixing holes.
Connect the 24 V DC control voltage supply to the M8 male feed socket using a compatible 4-pin cable.
Connect PROFIBUS communication cables to the B-coded M12 bus socket.
Attach binary sensors to the M12 input channels, ensuring signal levels conform to EN 61131-2, type 2 requirements.
Verify all M12 and M8 screw connections are securely fastened to maintain IP65/66/67 environmental protection.

Shipping & Returns

Global Express Shipping

Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
12-Month Warranty: Every industrial component is backed by our technical warranty.

FAQ

What is the BECKHOFF IP1002-B310?

The BECKHOFF IP1002-B310 is a decentralized Fieldbus Box equipped with an integrated PROFIBUS interface and 8 digital inputs, engineered for cabinet-free machine-level installations.

What communication protocol does the IP1002-B310 support?

The BECKHOFF IP1002-B310 supports the PROFIBUS DP communication protocol with automatic baud rate detection up to 12 Mbaud and DP-V1 extension capabilities.

How many digital inputs does the BECKHOFF IP1002-B310 feature?

The BECKHOFF IP1002-B310 features 8 digital input channels configured with M12 screw-type connections conforming to EN 61131-2, type 2 specifications.

What is the enclosure protection rating of the IP1002-B310?

The BECKHOFF IP1002-B310 features an IP65, IP66, and IP67 protection rating, ensuring reliable operation in harsh industrial environments without requiring a control cabinet.
