The BECKHOFF IP2022-B510 is a high-performance decentralised Fieldbus Box designed to connect digital actuators directly within CANopen network architectures. By facilitating direct machine mounting without an enclosure, this module simplifies field-level wiring and minimises control cabinet space requirements. It features 8 digital outputs that operate at 24 V DC, providing dependable control for valves, contactors, indicators, and small motor loads in industrial settings.
Engineered for harsh industrial environments, the BECKHOFF IP2022-B510 features a rugged polyamide housing offering IP65, IP66, or IP67 protection. It communicates via CANopen using a standard 5-pin M12 connector and supports automatic baud rate detection up to 1 Mbaud. The load and control voltages are supplied via compact M8 connections with downstream loop-through capabilities, facilitating efficient daisy-chain power distribution across multiple modules.
| Manufacturer | BECKHOFF |
| Model | IP2022-B510 |
| Product Type | Fieldbus Box |
| Housing Material | PA6 (Polyamide) |
| Installation / Mounting | 2 fixing holes, 3.5 mm diameter (for M3 screws) |
| Number of Outputs | 8 |
| Nominal Output Voltage | 24 V DC (-15 % / +20 %) |
| Max. Output Current | 2 A per channel (individually short-circuit proof) |
| Total Max. Output Current (Sum) | 4 A |
| Load Type | Ohmic, inductive, lamp load |
| Short-Circuit Current | Max. 4 A |
| Auxiliary Power Current | Typically 30 mA per channel |
| Fieldbus Protocol | CANopen |
| Data Transfer Rates | Automatic detection: 10 kbaud up to 1 Mbaud |
| Bus Interface Connection | 1 x M12 plug, 5-pin |
| Process Image Bit Width | 8 outputs |
| CANopen Features | Life/Node guarding, emergency object, variable mapping, store/restore configuration |
| Configuration Interface | Via KS2000 software tool or the system controller (SDOs) |
| Control Voltage Power Supply | 24 V DC (-15 % / +20 %) |
| Box Supply Current | 45 mA + sensor/auxiliary current (max. 0.5 A) |
| Electrical Isolation | Control voltage/fieldbus: 500 V; channels/control voltage: no |
| Power Connections | Feed: 1 x M8 male, 4-pin; Downstream: 1 x M8 female, 4-pin |
| Dimensions (W x H x D) | 30 mm x 175 mm x 26.5 mm |
| Operating Temperature | 0 to +55 Celsius |
| Storage Temperature | -25 to +85 Celsius |
| Protection Class | IP65, IP66, IP67 (conforms to EN 60529) |
| Vibration & Shock Resistance | Conforms to EN 60068-2-6 & EN 60068-2-27 |
| EMC Immunity / Emission | Conforms to EN 61000-6-2 & EN 61000-6-4 |
| Approvals | CE, UL |
| Interface / Connector | Function / Description |
|---|---|
| M12 Bus Interface (5-pin Plug) | CANopen network interface connection. Supports standard CAN wiring. |
| M12 Output Connectors (Screw Type) | Connection points for the 8 digital outputs to field-level actuators. |
| M8 Power Supply Feed (4-pin Male) | Main power connection input for control and load voltage supplies. |
| M8 Power Supply Downstream (4-pin Female) | Loop-through connector to pass control and load voltages to adjacent Fieldbus Boxes. |
