Beckhoff KL2798 Bus Terminal

SKU KL2798

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: BECKHOFF
  • Product No.: KL2798
  • Origin Germany
  • Product Type: Bus Terminal
  • Payment: T/T, Western Union
  • Weight: 1.0 kg
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

Bus Terminals
Quantità
Call sales Contact

Product Description

Description

The KL2798 is an 8-channel solid state relay output terminal designed for the Beckhoff Bus Terminal system. This module provides high-density, potential-free switching for AC and DC loads up to 30 V AC or 48 V DC. With a capacity of 2 A per channel and a total sum current of 10 A, it is an effective solution for space-saving control of multiple low-voltage loads. The terminal utilizes a 2-wire connection technology and features robust electrical isolation (500 V) between the K-bus and field potential.

Features

  • 8-channel solid state relay outputs (make contacts)
  • Potential-free switching for 30 V AC / 48 V DC loads
  • Maximum output current: 2 A per channel (∑ 10 A)
  • 2-wire connection technology
  • Compact design for high-density DIN rail mounting
  • Robust isolation (500 V K-bus/field potential)

Technical Specifications

Feature Specification
Manufacturer Beckhoff
Product Type Bus Terminal
Number of Outputs 8 (Make contacts)
Nominal Voltage 30 V AC / 48 V DC
Max. Output Current 2 A per channel (∑ 10 A)
Peak Current 5 A (100 ms); < 50 A (10 ms)
Electrical Isolation 500 V (K-bus/field potential)
Protection Rating IP20
Operating Temperature 0…55 degC
Weight Approx. 50 g

Installation Guidelines

  • Mounting: Install the KL2798 on a standard 35 mm DIN rail. Ensure the terminal is securely locked into place for proper power contact alignment.
  • Wiring: Uses 2-wire connection technology. Ensure conductors are sized to support the 2 A per channel load requirements.
  • Circuit Protection: Note that this terminal is not internally short-circuit proof. External fusing or protection must be installed to manage peak currents and short-circuit conditions.
  • Environment: Ensure ambient temperatures remain within 0 degC to 55 degC and humidity levels do not exceed 95% (non-condensing).
  • Isolation: Respect the breakdown voltage of 80 V when designing external circuits connected to these relays.
Shipping &amp; Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
How many output channels does the KL2798 have?
The KL2798 features 8 solid state relay output channels (make contacts).
What is the maximum current load for this terminal?
It supports 2 A per channel, with a maximum total sum current of 10 A.
Is the KL2798 short-circuit proof?
No, it is not internally short-circuit proof; external protection is required to handle peak currents.
What type of loads can this terminal switch?
It is designed to switch loads up to 30 V AC or 48 V DC.
