BECKHOFF KL6583 EnOcean Transceiver Module

SKU KL6583

Disponibile

12-month warranty
Free returns within 30 days

Manufacturer: BECKHOFF
Product No.: KL6583
Origin Germany
Product Type: EnOcean Modules
Payment: T/T, Western Union
Weight: 0.09 kg
Dimensions: Height: 57 mm, Upper part diameter: 72 mm, Main housing with flange: 110 mm
Shipping port: Xiamen
Warranty: 12 months

Product Description

Description

The BECKHOFF KL6583 is an external EnOcean transceiver module designed for bidirectional wireless communication with EnOcean-enabled sensors and actuators. Operating on the 868.35 MHz frequency band, this transceiver acts as the physical RF interface for the BECKHOFF KL6581 EnOcean Bus Terminal master. By positioning the KL6583 externally, system integrators can optimize radio coverage within building automation architectures while keeping the main I/O terminal block inside the control cabinet.

Engineered for wall or ceiling mounting, the housing of the BECKHOFF KL6583 features an integrated antenna and a dedicated cable feed-through. It connects directly to the KL6581 master using a 2 x 2-wire connection, allowing a distance of up to 500 meters between the transceiver and the I/O terminal. Power is supplied directly from the KL6581 master terminal, eliminating the need for an external local power source at the mounting site.

Features

Bidirectional EnOcean radio communication on the 868.35 MHz frequency band.
Direct connection to the KL6581 EnOcean master terminal via a 2 x 2-wire cable.
Extended installation range with support for up to 500 meters of connecting cable.
Integrated RF antenna housed inside the unit.
No separate software configuration required on the transceiver itself.
Compact, grey-white (RAL 9002) housing optimized for simple wall or ceiling flange mounting.

Applications

Building automation and building services management.
Wireless integration of self-powered EnOcean switches, temperature sensors, and occupancy detectors.
Industrial facilities requiring wireless sensor integration without heavy cabling.
Retrofitting existing spaces where hardwired sensor runs are impractical.

Technical Specifications

General

Parameter	Specification
Manufacturer	BECKHOFF
Exact Model	KL6583
Technology	EnOcean (bidirectional)
Frequency Band	868.35 MHz
Data Transfer Range	300 m in free field, approx. 30 m within buildings
Radio Telegrams	Dependent on sensor type (32-bit sensor ID, unlimited payload bytes)
Antenna	Integrated in the housing

Electrical and Connection

Parameter	Specification
Nominal Voltage	24 V DC (supplied via connected KL6581 master)
Current Consumption	Typical 20 mA (at 24 V DC)
Connection Interface	2 x 2-wire connection directly to the KL6581
Maximum Cable Length	500 m

Mechanical and Environmental

Parameter	Specification
Housing Design	Round upper part for ceiling/wall flange mounting, upper part with cable feed-through
Housing Color	Gray white (RAL 9002)
Dimensions	Height: 57 mm, Upper part diameter: 72 mm, Main housing with flange: 110 mm
Weight	Approx. 90 g
Protection Rating	IP40
Operating Temperature	0 to +55 Celsius
Storage Temperature	-25 to +85 Celsius
Relative Humidity	95%, non-condensing
Installation Position	Variable

Connections / Interfaces

Interface Type	Function
2 x 2-wire interface	Provides power supply (24 V DC) and serial data communication line to the KL6581 EnOcean Bus Terminal.

Installation Guidelines

Ensure the entire automation system and the associated KL6581 Bus Terminal are de-energized before mounting or wiring the transceiver.
Select an optimal physical location on the wall or ceiling to maximize line-of-sight RF communication with EnOcean sensors, keeping away from large metal objects.
Mount the flange base securely to the flat surface using appropriate hardware.
Route the 2 x 2-wire shielded connection cable through the integrated feed-through of the housing.
Connect the wiring directly to the corresponding terminals on the KL6581 Bus Terminal, ensuring correct polarity and shielding. Do not exceed the maximum cable limit of 500 meters.
Assemble the housing upper part onto the flange base.
Restore system power and verify the diagnostic status via the master KL6581 terminal.

Shipping & Returns

Global Express Shipping

Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
12-Month Warranty: Every industrial component is backed by our technical warranty.

FAQ

What is the main function of the BECKHOFF KL6583 transceiver?

The BECKHOFF KL6583 is a transceiver designed to transmit and receive wireless EnOcean RF signals at 868.35 MHz, relaying data directly to the BECKHOFF KL6581 Bus Terminal master.

How is the BECKHOFF KL6583 transceiver module powered?

The BECKHOFF KL6583 does not require an external local power supply; it is powered directly with 24 V DC over the connection cable from the KL6581 master Bus Terminal, drawing a typical current of 20 mA.

What is the maximum cable length between the BECKHOFF KL6583 and the KL6581 terminal?

The BECKHOFF KL6583 can be installed at a physical distance of up to 500 meters away from the KL6581 terminal using a 2 x 2-wire communication and power cable.

Does the BECKHOFF KL6583 transceiver require manual software configuration?

No, the BECKHOFF KL6583 does not require separate software configuration. All communication parameters, sensor pairing, and data processing are managed directly through the KL6581 Bus Terminal and TwinCAT system configuration.

Can the BECKHOFF KL6583 be installed outdoors?

The BECKHOFF KL6583 features an IP40 protection rating and an operating temperature range of 0 to +55 Celsius, meaning it is designed for indoor use and must be protected in an appropriate enclosure if used in outdoor or high-moisture environments.
