Bently Nevada

Bently Nevada 128275-01F 130944-01 Future Expansion Faceplate

SKU 128275-01F 130944-01

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Bently Nevada
  • Product No.: 128275-01F 130944-01
  • Origin United States
  • Product Type: Future Expansion Faceplate
  • Barcode: 8537101190
  • Payment: T/T, Western Union
  • Weight: 0.05 kg
  • Dimensions: 26 mm x 28 mm x 240 mm (H x W x D)
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

3500/05 Future Expansion Faceplate

Product Documentation

Technical Datasheet (PDF) Complete specifications and technical drawings.

Technical Datasheet

Bently Nevada 128275-01F 130944-01 Future Expansion Faceplate

Download Open in new tab
Quantità
Call sales Contact

Product Description

Description

The Bently Nevada 128275-01F 130944-01 is a full-height blank front panel designed for unused module positions within the Bently Nevada 3500 Series rack. It is utilized when a rack slot is reserved for future system expansion and is not occupied by an active monitoring, relay, communication, or other functional module.

This Future Expansion Faceplate provides physical coverage for unused full-height rack positions. It maintains a clean installation environment while reducing the exposure of open rack slots to dust, oil, foreign objects, and accidental physical contact. The device does not perform signal acquisition, signal conditioning, alarm processing, communication, or relay switching functions. The 128275-01F is associated with part number 130944-01 for standard full-height slot cover applications and can be removed when an active 3500 Series module is installed.

Features

  • Covers unused full-height module positions in 3500 Series racks.
  • Associated with part number 130944-01 full-height monitor blank front panel.
  • Includes mounting screws for securing the panel.
  • Holds all 3500 monitor modules and rack power supplies.
  • Supports Full-Size Rack (19-inch EIA, 14 module slots) and Mini-Rack (12-inch, 7 module slots) configurations.
  • Supports Panel Mount, Rack Mount, and Bulkhead Mount rack formats.

Applications

  • Slot protection for reserved full-height positions in Bently Nevada 3500 Series system racks.
  • Enclosure protection against dust, oil, and accidental contact in machinery monitoring systems.

Ordering Information

Part Number Description
130944-01 Full-height Monitor Blank Front Panel (qty 1, includes screws)

Technical Specifications

Category Specification
Manufacturer Bently Nevada
Model 128275-01F 130944-01
Product Type Future Expansion Faceplate / Full-height Monitor Blank Front Panel
Power Supply N/A
Power Consumption 0 W
Operating Temperature -40 degC ... +85 degC
Storage Temperature -40 degC ... +85 degC
Country of Origin USA
Dimensions 2.6 cm x 2.8 cm x 24 cm
Weight 0.05 kg

Installation Guidelines

  • Place the blank panel over an unpopulated full-height rack position in a standard Bently Nevada 3500 Series rack.
  • Secure the panel in position using the provided mounting screws.
  • Remove the faceplate prior to installing an active 3500 Series monitoring module in the reserved slot.

Compliance and Certifications

  • EMC Directives: EN 61000-6-2, EN 61000-6-4
  • Electrical Safety: EN 61010-1
  • Hazardous Area Approvals: CSA/NRTL/C (Class I, Zone 2; Class I, Division 2, Groups A, B, C, D); ATEX/IECEx (Ex II 3 G)
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What is the Bently Nevada 128275-01F 130944-01 used for?
The Bently Nevada 128275-01F 130944-01 is a full-height blank front panel used to cover unused module positions reserved for future expansion in a 3500 Series rack.
Which system is the faceplate compatible with?
The faceplate is designed for use in standard full-height positions within the Bently Nevada 3500 Series Machinery Condition Monitoring System rack.
Does the 128275-01F 130944-01 require electrical power?
No. The faceplate is a passive physical cover with a power supply rating of N/A and 0 W power consumption.
What are the operating temperature limits for this faceplate?
The operating temperature range for the faceplate is -40 degC to +85 degC.
