330103-00-10-10-02-00: 3300 XL 8 mm proximity probe with M10 x 1 threads, 0 mm unthreaded length (Option 00), 100 mm case length (Option 10), and 1.0 m total system length (Option 10). This eddy-current displacement transducer is engineered for non-contact shaft vibration and axial position measurements in critical rotating machinery. Designed to operate within the 3300 XL 8 mm proximity transducer system, this unit pairs with a matching 3300 XL Proximitor sensor and extension cable to maintain the required electrical calibration.
This configuration utilizes a standard miniature ClickLoc coaxial connector (Option 02) and is supplied without agency approvals (Option 00). The probe features an 8 mm tip diameter and is constructed without integral armor to suit installations where mechanical protection is not required. It functions as a primary sensor for monitoring shaft vibration, radial position, and axial thrust in industrial fluid-film bearing applications.
| Option | Code | Description |
|---|---|---|
| Orderable Part Number | 330103-00-10-10-02-00 | 3300 XL 8 mm Proximity Probe, M10 x 1 thread |
| A - Unthreaded Length | 00 | 0 mm |
| B - Case Length | 10 | 100 mm |
| C - Total Length | 10 | 1.0 meter (3.3 feet) |
| D - Connector/Cable | 02 | Miniature ClickLoc connector, standard cable |
| E - Agency Approval | 00 | Not required |
| Manufacturer | Bently Nevada |
| Model | 330103 |
| System Compatibility | 3300 XL 8 mm Proximity Transducer System |
| Probe Diameter | 8 mm |
| Thread Size | M10 x 1 |
| Case Length | 100 mm |
| Unthreaded Length | 0 mm |
| Total Length | 1.0 m |
| Connector Type | Miniature ClickLoc coaxial |
| Cable Type | Standard |
| Linear Range | 2 mm (80 mil) |
| Operating Temperature | -51 degC to +177 degC |
| Agency Approvals | Not required (Option 00) |
| Interface | Function |
| Coaxial Center Conductor | Signal |
| Coaxial Outer Shield | Common / Shield |
| ClickLoc Connector | Secure coaxial coupling to 330130 extension cable |
Ensure the probe is mounted using the correct thread pitch (M10 x 1) and that the probe tip has adequate clearance according to the required gap voltage settings. The probe should be installed in a location free from excessive physical vibration. Use standard probe mounting brackets for installation. Ensure the extension cable connection is tight and secured with the ClickLoc connector mechanism; environmental protection via connector protectors is recommended if the connection is exposed to moisture or oil.
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 330103-00-10-10-02-00
Country of origin:United States
Product Type: 3300 XL 8 mm Proximity Probe
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 140g
Dimensions: 45 mm x 95 mm x 95 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months
