Bently Nevada

Bently Nevada 138493-01 Replacement DIN-Mountmounting Pad

SKU 138493-01

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Bently Nevada
  • Product No.: 138493-01
  • Origin United States
  • Product Type: Mounting Adapter
  • Barcode: 8537101190
  • Payment: T/T, Western Union
  • Weight: 0.1 kg
  • Dimensions: 65 mm x 35 mm x 15 mm (W x H x D)
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

3300 XL Mounting Adapters

Product Documentation

Technical Datasheet (PDF) Complete specifications and technical drawings.

Technical Datasheet

Bently Nevada 138493-01 Replacement DIN-Mountmounting Pad

Download Open in new tab
Quantità
Call sales Contact

Product Description

Description

The Bently Nevada 138493-01 is a replacement DIN-mount mounting pad designed for supporting and securing Proximitor Sensors within the 3300 XL Proximity Transducer System. The pad enables direct installation of compatible sensor housings onto standard 35 mm DIN rail structures. It serves as a mechanical interface component to maintain stable positioning of the 138493-01 pad assembly in industrial vibration and position monitoring installations.

Features

  • Compatible with 35 mm DIN rail mounting configurations
  • Direct replacement spare part for 3300 XL series Proximitor Sensor installations
  • Designed for mechanical retention and alignment on standard mounting rails

Technical Specifications

Parameter Specification
Manufacturer Bently Nevada
Part Number 138493-01
Component Type Replacement DIN-Mount Mounting Pad
Product Series 3300 XL Series
Compatible Rail Standard 35 mm DIN Rail

Installation Guidelines

  • Ensure the mounting surface or 35 mm DIN rail is clean and free of debris prior to attaching the pad.
  • Secure the mounting pad to the target Proximitor Sensor body or enclosure according to standard hardware procedures.
  • Snap or slide the assembly firmly onto the 35 mm DIN rail until properly seated and latched.
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What standard rail type does the mounting pad attach to?
The mounting pad attaches directly to standard 35 mm DIN rails.
Which product line is this replacement component designed for?
The component is designed specifically as a replacement spare for the Bently Nevada 3300 XL series Proximitor Sensors.
