Bently Nevada 138708-01 Shaft Absolute I/O Module with Internal Terminations

SKU 138708-01

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Bently Nevada
  • Product No.: 138708-01
  • Origin United States
  • Product Type: Shaft Absolute I/O Module
  • Barcode: 8537101190
  • Payment: T/T, Western Union
  • Weight: 0.4 kg
  • Dimensions: 241.3 mm x 120.7 mm x 25.4 mm (W x H x D)
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

I/O Modules

Product Documentation

Technical Datasheet (PDF) Complete specifications and technical drawings.

Technical Datasheet

Bently Nevada 138708-01 Shaft Absolute I/O Module with Internal Terminations

Download Open in new tab
Quantità
Call sales Contact

Product Description

Description

The Bently Nevada 138708-01 is a Shaft Absolute I/O Module with Internal Terminations designed for machinery protection and condition monitoring within the 3500/42M Proximitor/Seismic Monitor system. Interfacing directly with the 3500/42M main monitor board via the 3500 backplane, the module routes field signals from proximity, Velomitor, or Seismoprobe transducers to condition raw signal inputs and measure critical parameters like shaft absolute vibration. The board continuously feeds static and dynamic variables to the 3500 Rack Configuration Software and host monitoring systems, providing continuous alarm setpoint evaluation against active static values to safeguard industrial rotating machinery.

Features

  • Direct connection for internal field wiring terminations without requiring external termination blocks
  • Input signal processing for proximity transducers, Velomitors, and Seismoprobes
  • Integrated signal routing for shaft absolute vibration measurements within the 3500/42M Proximitor/Seismic Monitor
  • Standard 8-pin and 10-pin Euro style internal connector header compatibility

Applications

  • Shaft absolute vibration measurement on industrial rotating machinery
  • Continuous machinery protection and alarm monitoring
  • Operations and maintenance asset condition monitoring in 3500 Series racks

Ordering Information

Ordering Code / Part Number Description
3500/42-A07-BXX 3500/42M Monitor with Shaft Absolute I/O Module with Internal Terminations
138708-01 Shaft Absolute I/O Module with internal terminations
00517018 3500/42M Shaft Absolute I/O Module 8-pin connector shunt
00580434 Internal I/O Module connector header, Euro style, 8-pin
00580432 Internal I/O Module connector header, Euro style, 10-pin

Technical Specifications

Parameter Specification
Manufacturer Bently Nevada
Model 138708-01
Module Type Shaft Absolute I/O Module with Internal Terminations
Supported System 3500/42M Proximitor/Seismic Monitor
Compatible Transducers Proximity Transducers, Velomitors, Seismoprobes
Output Supply (Prox & Velomitor) U = 23.9 V, I = 45.5 mA, P = 1.09 W
Output Supply (Prox & Seismoprobe) U = 6.82 V, I = 45.5 mA, P = 0.31 W
Firmware Requirement 3500/42M Module Firmware, revision B or later
Software Requirement 3500/01 Software version 2.61 or later; DM2000 Software version 3.10 or later

Installation Guidelines

  • Install the 138708-01 module into the rear slot of the 3500 rack directly behind the corresponding 3500/42M main monitor board.
  • Wire field transducer leads directly to the internal Euro style screw terminal connectors.
  • Verify that external termination blocks are not used with this module, as it uses direct internal terminations.
  • Secure the card in place using the chassis retaining screws to ensure stable ground contact through the 3500 rack frame.

Compliance and Certifications

Standard / Directive Detail
CE Directives CE Marked
CSA / NRTL / C Class 1, Division 2 (Option B01)
ATEX / IECEx / CSA Class 1, Zone 2 (Option B02)
