The 190501-07-00-00 Velomitor CT Velocity Transducer is a specialized, low-frequency piezoelectric sensor designed for measuring casing vibration velocity. This configuration features a 3/8-in 24 to 1/2-in 20 plate stud (Option 07) for mounting, a MIL-C-5015 connection interface (Option 00), and is supplied with no hazardous area approvals (Option 00). The Velomitor CT is optimized for monitoring cooling tower and air-cooled heat-exchanger fan assemblies typically operating at speeds of 90 rpm and above.
Engineered to detect vibration amplitudes generated by fan rotors, motors, and speed reducers, this transducer provides reliable data for identifying machine malfunctions such as unbalance and misalignment. The transducer’s internal electronics are electrically isolated from the case, and it features a 316L stainless steel housing suitable for industrial environments. Proper installation on the bearing housing or machine casing is essential to maintain amplitude and frequency response and to prevent false signal generation.
| Option | Code on This SKU | Description |
|---|---|---|
| Orderable Part Number | 190501-07-00-00 | Velomitor CT Velocity Transducer |
| A - Mounting Hardware | 07 | Plate Stud 3/8-in 24 to 1/2-in 20 |
| B - Connection | 00 | MIL-C-5015 connection interface |
| C - Agency Approval | 00 | No Approvals |
| Parameter | Specification |
|---|---|
| Sensitivity | 3.94 mV/mm/s (100 mV/in/s) +/- 5% |
| Frequency Response | 3.0 Hz to 900 Hz (+/- 1.0 dB); 1.5 Hz to 1.0 kHz (+/- 3.0 dB) |
| Velocity Range | 63.5 mm/s pk (2.5 in/s pk) |
| Case Material | 316L stainless steel |
| Connector | 2-pin 316L stainless steel MIL-C-5015, top exit |
| Operating Temperature | -40 degC to +85 degC |
| Storage Temperature | -40 degC to +100 degC |
| Weight | Less than 297 g (10.5 oz) typical |
| Mounting Torque | 4.5 N-m +/- 0.6 N-m (40 in-lbf +/- 5 in-lbf) |
| Magnetic Field Susceptibility | Less than 0.0068 mm/s/gauss @ 50 gauss, 50-60 Hz |
| Shock Limit | 5000 g pk maximum |
Install the Velomitor CT transducer directly on the bearing housing or machine casing. Use the provided 3/8-in 24 to 1/2-in 20 plate stud for mounting, ensuring a torque of 4.5 N-m. Ensure the mounting surface is clean and flat to guarantee accurate vibration transmission. The transducer can be mounted in any orientation. If using conduit, ensure proper sealing to maintain environmental integrity. For hazardous areas, refer to the Approvals Quick Reference Guide (108M1756) for compliant installation procedures.
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 190501-07-00-00
Country of origin:United States
Product Type: Velomitor CT Velocity Transducer
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 297g
Dimensions: 2cm x 26.4cm x 26.3cm
Shipping port: Xiamen
Warranty: 12 months
