The 21000-16-05-30-026-04-02 is a robust Proximity Probe Housing Assembly designed for industrial machinery vibration and position monitoring. This configuration utilizes a 3300 XL 8 mm proximity probe integrated into an aluminum body with a 304 stainless steel sleeve, meeting API 670 standards for externally mounted proximity probe housings. The assembly ensures critical sensor protection and accurate gap management in demanding environments.
This unit features a 0.5 m probe cable, a 3.0 inch standoff adapter, and a 2.6 inch probe penetration depth. The assembly is configured with a 3/4-14 NPT mounting thread and includes a 3/4-14 NPT plug fitting, providing a secure and sealed installation for the probe within the machine casing. It is engineered to prevent resonance and allow for precise alignment of the transducer tip relative to the target surface.
| Option | Code | Description |
|---|---|---|
| Part Number | 21000-16-05-30-026-04-02 | Proximity Probe Housing Assembly |
| A - Probe | 16 | 3300 XL 8 mm probe |
| B - Cable Length | 05 | 0.5 m (20 in) |
| C - Standoff Adapter | 30 | 3.0 in length |
| DDD - Probe Penetration | 026 | 2.6 in depth |
| EE - Fittings | 04 | One 3/4-14 NPT plug only |
| FF - Mounting Thread | 02 | 3/4-14 NPT |
| Manufacturer | Bently Nevada |
| Part Number | 21000-16-05-30-026-04-02 |
| Body Material | Aluminum with 304 stainless steel sleeve |
| Weight | 1.1 kg (2.4 lb) |
| Temperature Range | -51 degC to +177 degC (-60 degF to +351 degF) |
| Probe Type | 3300 XL 8 mm |
| Mounting | 3/4-14 NPT |
Ensure the probe lead is longer than the sleeve to facilitate connection. For penetration lengths exceeding 300 mm (12 inches), install additional sleeve support to mitigate resonance. When installing the 3/4-14 NPT fittings, ensure proper thread sealing practices are followed to maintain environmental integrity. Verify nominal probe gap during installation as per the specific transducer system user guide (e.g., 141078 for 3300 XL 8 mm systems).
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 21000-16-05-30-026-04-02
Country of origin:United States
Product Type: Proximity Probe Housing Assemblies
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 1100g
Dimensions: 8.5cm x 8.5cm x 30.5cm
Shipping port: Xiamen
Warranty: 12 months
