The 31000-16-05-35-026-03-02 is a Bently Nevada proximity probe housing assembly, configured specifically for the 3300 XL 8 mm proximity probe system. This assembly is designed to provide mechanical and environmental protection for proximity probes mounted through machine cases, facilitating radial vibration and position measurements. Constructed from polyphenylene sulfide (PPS), this housing offers superior corrosion resistance while allowing external access to the transducer for gap adjustments or probe replacements without requiring machine disassembly.
This specific configuration includes a 3.5-inch standoff adapter and a 2.6-inch probe penetration depth, utilizing a 3/4-14 NPT mounting thread. It is supplied with an M20 conduit fitting and two plugs, ensuring compatibility with standard industrial cable and conduit systems. This housing assembly adheres to API 670 standards for externally mounted proximity probe housings.
| Option | Code | Description |
|---|---|---|
| Orderable Part Number | 31000-16-05-35-026-03-02 | 31000 Proximity Probe Housing Assembly |
| A - Probe with Connector | 16 | 3300 XL 8 mm probe |
| B - Probe Cable Length | 05 | 0.5 m (20 in) |
| C - Standoff Adapter Length | 35 | 3.5 in |
| D - Probe Penetration | 026 | 2.6 in |
| E - Fittings | 03 | Two plugs, one M20 fitting |
| F - Mounting Thread | 02 | 3/4-14 NPT |
| Manufacturer | Bently Nevada |
| Part Number | 31000-16-05-35-026-03-02 |
| Housing Material | Polyphenylene Sulfide (PPS), Stainless Steel |
| Probe Compatibility | 3300 XL 8 mm |
| Mounting Interface | 3/4-14 NPT |
| Standard Compliance | API 670 |
| Environmental | Corrosion-resistant |
Ensure that the machine casing is properly affixed to the bearing to maintain an accurate relative vibration signal. Install the outer sleeve into the machine case, then insert the probe sleeve to adjust the probe gap. The housing design permits full external access, allowing the user to reconnect probe cables and tighten housing cover captive screws after installation. Always verify thread engagement and seal unused holes with the provided plugs to maintain environmental integrity.
The 31000 series housing assemblies are compliant with the American Petroleum Institute (API) 670 Standard. When installed with an approved Bently Nevada transducer system and appropriate safety barriers, the assembly is suitable for use in intrinsically safe hazardous area applications.
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 31000-16-05-35-026-03-02
Country of origin:United States
Product Type: Gruppi alloggiamento per sonda di prossimità in inglese
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 1200g
Dimensions: 30.02cm x 12cm x 9.14cm
Shipping port: Xiamen
Warranty: 12 months
