Bently Nevada 330101-00-18-10-02-00 Proximity Probes
Bently Nevada 330101-00-18-10-02-00 Proximity Probes
Bently Nevada 330101-00-18-10-02-00 Proximity Probes
1 / 3

Bently Nevada

Bently Nevada 330101-00-18-10-02-00 3300 XL 8 mm Proximity Probe

SKU 330101-00-18-10-02-00

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Bently Nevada
  • Product No.: 330101-00-18-10-02-00
  • Origin United States
  • Product Type: 3300 XL 8 mm Proximity Probe
  • Barcode: 8537101190
  • Payment: T/T, Western Union
  • Weight: 0.14 kg
  • Dimensions: 45 mm x 95 mm x 95 mm (H x W x D)
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

3300 XL Proximity Probes

Product Documentation

Technical Datasheet (PDF) Complete specifications and technical drawings.

Technical Datasheet

Bently Nevada 330101-00-18-10-02-00 3300 XL 8 mm Proximity Probe

Download Open in new tab
Quantità
Call sales Contact

Product Description

Description

Non-contact eddy-current displacement measurement probe for 3300 XL monitoring chains; orderable configuration 330101-00-18-10-02-00 features a 3/8-24 UNF threaded steel body with a 1.8 in case length (Option 18), 1.0 m total system length (Option 10), and a standard miniature coaxial ClickLoc connector (Option 02) without agency approvals (Option 00).

This transducer is designed for continuous duty in 3300 XL 8 mm monitoring systems, providing precise gap measurements between the probe tip and the observed conductive surface. It pairs with a 3300 XL Proximitor sensor and extension cable to form a complete system capable of detecting shaft vibration, axial position, and rotor speed in critical rotating machinery. The unthreaded design (0.0 in unthreaded length per Option 00) requires specific mounting bracket clearance for installation in standard bearing housings.

Features

  • 3300 XL 8 mm probe assembly with 3/8-24 UNF threads
  • Option 18: 1.8 in case length
  • Option 10: 1.0 m system length
  • Option 02: Miniature coaxial ClickLoc connector with standard cable
  • Option 00: No agency approvals required
  • Non-contact measurement of shaft radial vibration, axial position, and speed
  • Compatible with 3300 XL series Proximitor sensors and extension cables

Applications

  • Steam and gas turbine vibration monitoring
  • Compressor and pump shaft displacement measurement
  • Rotor axial position and thrust monitoring
  • General purpose industrial rotating machinery protection

Ordering Information

Option Code on This SKU Description
Orderable Part Number 330101-00-18-10-02-00 3300 XL 8 mm Proximity Probe, 3/8-24 UNF
A - Unthreaded Length 00 0.0 in
B - Case Length 18 1.8 in
C - Total Length 10 1.0 m
D - Connector/Cable 02 Miniature coaxial ClickLoc connector, standard cable
E - Agency Approval 00 Not required

Technical Specifications

Manufacturer Bently Nevada (Baker Hughes)
Part Number 330101-00-18-10-02-00
Probe Diameter 8 mm
Thread Size 3/8-24 UNF
Case Length 1.8 in
Unthreaded Length 0.0 in
Total Length 1.0 m
Connector Type Miniature coaxial ClickLoc
Cable Type Standard
Linearity Within 0.025 mm (1 mil) of a straight line
Operating Temperature -55 degC to +177 degC
Storage Temperature -55 degC to +177 degC

Installation Guidelines

  • Ensure the probe is gapped according to system manual specifications (typically 1.27 mm or 50 mils).
  • Mounting must provide electrical isolation from the machine case if required; use appropriate phenolic or insulated brackets.
  • Ensure coaxial connectors are clean and free of moisture or debris before mating; use silicone self-fusing tape to seal connections in exposed environments.
  • Route cables away from high-voltage lines to prevent electromagnetic interference.
  • Verify the system total length (probe + extension cable) matches the Proximitor sensor calibration (1.0 m, 5.0 m, or 9.0 m).
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What does the 18 code in the part number 330101-00-18-10-02-00 represent?
The 18 code specifies a case length of 1.8 inches for this 3300 XL 8 mm probe.
Does this probe model require hazardous area certification?
No. The Option E code 00 indicates that this specific configuration is not required to carry hazardous area approvals (CSA, ATEX, or IECEx).
Is this probe compatible with a 5-meter Proximitor sensor?
No. This probe is part of a 1.0-meter system length configuration (Option C = 10) and must be paired with a matching 1.0-meter 3300 XL Proximitor sensor system.
What type of connector does this probe use?
This probe uses a standard miniature coaxial ClickLoc connector (Option D = 02).
Reviews

More from this brand

Bently Nevada 168679-01-01-01-02-03-05-01-01-00-02-02 ADRE 408 DSPi Dynamic Signal Processing Instrument
168679-01-01-01-02-03-05-01-01-00-02-02Bently Nevada 168679-01-01-01-02-03-05-01-01-00-02-02 ADRE 408 DSPi Dynamic Signal Processing Instrument
Bently Nevada 3300/50-02-01-00-00 Tachometer Monitor
3300/50-02-01-00-00Bently Nevada 3300/50-02-01-00-00 Tachometer Monitor
Bently Nevada 3300/16-02-01-01-01-00-00 XY/GAP Dual Vibration Monitor
3300/16-02-01-01-01-00-00Bently Nevada 3300/16-02-01-01-01-00-00 XY/GAP Dual Vibration Monitor
Bently Nevada 87890-01 Monitor Circuit Assembly for 3300/03 System Monitor
87890-01Bently Nevada 87890-01 Monitor Circuit Assembly for 3300/03 System Monitor

330101-00-18-10-02-00

Stock & lead time on request

Call
  • Bently Nevada 330101-00-18-10-02-00 Proximity Probes
  • Bently Nevada 330101-00-18-10-02-00 Proximity Probes
  • Bently Nevada 330101-00-18-10-02-00 Proximity Probes
1 3

Bently Nevada 330101-00-18-10-02-00 3300 XL 8 mm Proximity Probe

Only 7 item(s) left in stock

  • Manufacturer: Bently Nevada

  • Product No.: 330101-00-18-10-02-00

  • Country of origin:United States

  • Product Type: 3300 XL 8 mm Proximity Probe

  • Barcode: 8537101190

  • Payment: T/T, Western Union

  • Weight: 140g

  • Dimensions: 45 mm x 95 mm x 95 mm (H x W x D)

  • Shipping port: Xiamen

  • Warranty: 12 months

Visualizza dettagli completi
Product Description
FAQ
Shipping Returns
Additional details
Reviews

Description

Non-contact eddy-current displacement measurement probe for 3300 XL monitoring chains; orderable configuration 330101-00-18-10-02-00 features a 3/8-24 UNF threaded steel body with a 1.8 in case length (Option 18), 1.0 m total system length (Option 10), and a standard miniature coaxial ClickLoc connector (Option 02) without agency approvals (Option 00).

This transducer is designed for continuous duty in 3300 XL 8 mm monitoring systems, providing precise gap measurements between the probe tip and the observed conductive surface. It pairs with a 3300 XL Proximitor sensor and extension cable to form a complete system capable of detecting shaft vibration, axial position, and rotor speed in critical rotating machinery. The unthreaded design (0.0 in unthreaded length per Option 00) requires specific mounting bracket clearance for installation in standard bearing housings.

Features

  • 3300 XL 8 mm probe assembly with 3/8-24 UNF threads
  • Option 18: 1.8 in case length
  • Option 10: 1.0 m system length
  • Option 02: Miniature coaxial ClickLoc connector with standard cable
  • Option 00: No agency approvals required
  • Non-contact measurement of shaft radial vibration, axial position, and speed
  • Compatible with 3300 XL series Proximitor sensors and extension cables

Applications

  • Steam and gas turbine vibration monitoring
  • Compressor and pump shaft displacement measurement
  • Rotor axial position and thrust monitoring
  • General purpose industrial rotating machinery protection

Ordering Information

Option Code on This SKU Description
Orderable Part Number 330101-00-18-10-02-00 3300 XL 8 mm Proximity Probe, 3/8-24 UNF
A - Unthreaded Length 00 0.0 in
B - Case Length 18 1.8 in
C - Total Length 10 1.0 m
D - Connector/Cable 02 Miniature coaxial ClickLoc connector, standard cable
E - Agency Approval 00 Not required

Technical Specifications

Manufacturer Bently Nevada (Baker Hughes)
Part Number 330101-00-18-10-02-00
Probe Diameter 8 mm
Thread Size 3/8-24 UNF
Case Length 1.8 in
Unthreaded Length 0.0 in
Total Length 1.0 m
Connector Type Miniature coaxial ClickLoc
Cable Type Standard
Linearity Within 0.025 mm (1 mil) of a straight line
Operating Temperature -55 degC to +177 degC
Storage Temperature -55 degC to +177 degC

Installation Guidelines

  • Ensure the probe is gapped according to system manual specifications (typically 1.27 mm or 50 mils).
  • Mounting must provide electrical isolation from the machine case if required; use appropriate phenolic or insulated brackets.
  • Ensure coaxial connectors are clean and free of moisture or debris before mating; use silicone self-fusing tape to seal connections in exposed environments.
  • Route cables away from high-voltage lines to prevent electromagnetic interference.
  • Verify the system total length (probe + extension cable) matches the Proximitor sensor calibration (1.0 m, 5.0 m, or 9.0 m).
Key Features:
#3300 XL #Proximity Probes

Product Documentation

Technical Datasheet (PDF) Complete specifications and technical drawings.

Technical Datasheet

Bently Nevada 330101-00-18-10-02-00 3300 XL 8 mm Proximity Probe

Download Open in new tab

What does the 18 code in the part number 330101-00-18-10-02-00 represent?
The 18 code specifies a case length of 1.8 inches for this 3300 XL 8 mm probe.

Does this probe model require hazardous area certification?
No. The Option E code 00 indicates that this specific configuration is not required to carry hazardous area approvals (CSA, ATEX, or IECEx).

Is this probe compatible with a 5-meter Proximitor sensor?
No. This probe is part of a 1.0-meter system length configuration (Option C = 10) and must be paired with a matching 1.0-meter 3300 XL Proximitor sensor system.

What type of connector does this probe use?
This probe uses a standard miniature coaxial ClickLoc connector (Option D = 02).

Global Express Shipping

  • Standard Delivery: 4-6 Business Days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries, including rapid delivery to Saudi Arabia and UAE.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our professional technical warranty.

Orders are processed and delivered Monday-Friday (excluding public holidays).


For full eligibility, restocking fees, and international return details, please view our official Refund & Return Policy .
