Option 00 (0.0 in unthreaded length) and Option 36 (3.6 in case length) specify this 330101-00-36-10-01-00 3300 XL 8 mm proximity probe configuration. This non-contact, eddy-current transducer is a core element of the 3300 XL monitoring system, designed for accurate measurement of shaft vibration, axial position, and rotor speed in critical rotating machinery environments.
This probe utilizes the standard 3/8-24 UNF thread profile and is supplied with a 1.0 m length cable terminating in a miniature coaxial ClickLoc connector. It is designed to interface with the 330180 Proximitor Sensor and 330130 Extension Cable. Unlike armored variants, this configuration features standard unarmored cabling suited for protected conduit environments where additional mechanical abrasion resistance is not required.
This transducer is used for continuous condition monitoring of critical rotating equipment, including steam turbines, gas turbines, centrifugal compressors, fans, pumps, and gearboxes. It provides the input signal for vibration analysis and axial position protection, enabling early detection of machinery degradation.
| Option | Code on This SKU | Description |
|---|---|---|
| Orderable Part Number | 330101-00-36-10-01-00 | 3300 XL 8 mm Proximity Probe, 3/8-24 UNF |
| A - Unthreaded Length | 00 | 0.0 in |
| B - Case Length | 36 | 3.6 in |
| C - Total Length | 10 | 1.0 m |
| D - Connector/Cable | 01 | Miniature coaxial ClickLoc connector, standard cable |
| E - Agency Approval | 00 | Not required |
| Manufacturer | Bently Nevada (Baker Hughes) | |
| Part Number | 330101-00-36-10-01-00 | |
| Probe Diameter | 8 mm | |
| Thread Size | 3/8-24 UNF | |
| Total System Length | 1.0 m | |
| Cable Type | Standard (Unarmored) | |
| Connector Type | Miniature coaxial ClickLoc | |
| Linear Range | 2 mm (80 mil) | |
| Operating Temperature | -51 degC to +177 degC | |
| Case Material | AISI 303 or 304 Stainless Steel | |
| Agency Approvals | Not required (Option 00) |
Ensure the probe is installed with the correct gap as specified by the machinery monitoring configuration. Maintain proper signal path integrity by using 3300 XL compatible extension cables. Probes must be mounted to minimize signal noise, avoiding electrical interference from nearby high-voltage equipment. Ensure all connections are fully seated using the ClickLoc connector mechanism to prevent signal loss.
This specific part number (Option 00) does not carry hazardous area certifications (CSA, ATEX, or IECEx). It is intended for non-hazardous locations or applications where agency approvals are not required.
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 330101-00-36-10-01-00
Country of origin:United States
Product Type: 3300 XL 8 mm Proximity Probe
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 140g
Dimensions: 45 mm x 95 mm x 95 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months
