Description

330101-00-41-10-02-05: 3300 XL 8 mm proximity probe, 3/8-24 UNF, Option 00 (0.0 in unthreaded length), Option 41 (4.1 in case length), Option 10 (1.0 m total length), Option 02 (standard connector), and Option 05 (CSA, ATEX, IECEx approvals). This eddy-current displacement probe is a primary component of the 3300 XL 8 mm transducer system, used for critical machinery monitoring, including shaft vibration and axial position measurements in turbines, compressors, and large rotating equipment.

This configuration utilizes a standard 3/8-24 UNF threaded body without armor. The probe is engineered for compatibility with 3300 XL Proximitor sensors and extension cables, providing the necessary signal chain for non-contact measurement in hazardous area applications as specified by the Option 05 certification.

Features

• 3/8-24 UNF thread size (Option 00 unthreaded, 4.1 in case length)
• 1.0 meter total system length
• Standard Miniature coaxial ClickLoc connector
• CSA, ATEX, IECEx hazardous area approvals (Option 05)
• Non-contact, eddy-current measurement technology
• Compatible with 3300 XL Proximitor sensors and extension cables

Applications

• Turbine and compressor shaft vibration monitoring
• Rotor axial position measurement
• Critical rotating machinery protection
• Hazardous area environments (CSA/ATEX/IECEx)

Ordering Information

Technical Specifications

Installation Guidelines

• Ensure proper probe gap settings according to the 3300 XL monitoring system manual.
• Use appropriate torque (finger tight) for ClickLoc connectors; do not over-tighten.
• Maintain proper cable routing and strain relief to avoid signal noise.
• Verify hazardous area installation practices comply with local codes for Option 05 certified devices.

Compliance and Certifications

• CSA, ATEX, IECEx approved for hazardous locations (Option 05)
