Bently Nevada 330102-00-80-10-02-05
Bently Nevada 330102-00-80-10-02-05
Bently Nevada 330102-00-80-10-02-05
1 / 3

Bently Nevada

Bently Nevada 330102-00-80-10-02-05 3300 XL 8 mm Proximity Probe

SKU 330102-00-80-10-02-05

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Bently Nevada
  • Product No.: 330102-00-80-10-02-05
  • Origin United States
  • Product Type: 3300 XL 8 mm Proximity Probe
  • Barcode: 8537101190
  • Payment: T/T, Western Union
  • Weight: 0.14 kg
  • Dimensions: 45 mm x 95 mm x 95 mm (H x W x D)
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

3300 XL Proximity Probes

Product Documentation

Technical Datasheet (PDF) Complete specifications and technical drawings.

Technical Datasheet

Bently Nevada 330102-00-80-10-02-05 3300 XL 8 mm Proximity Probe

Download Open in new tab
Quantità
Call sales Contact

Product Description

Description

330102-00-80-10-02-05: 3300 XL 8 mm proximity probe with armor (Option 80, 8.0 in case length), 1.0 m total length (Option 10), and CSA/ATEX/IECEx approvals (Option 05). This transducer system provides non-contact, eddy-current displacement measurement for critical machinery monitoring, including shaft vibration and axial position applications. The 330102 series includes an integrated protective armor for enhanced mechanical durability in harsh environments. This configuration features a 0.0 in unthreaded length (Option 00) and utilizes the standard Miniature coaxial ClickLoc connector (Option 02) for secure connectivity within 3300 XL monitoring chains.

Features

  • 3300 XL 8 mm proximity probe with armored casing for improved mechanical protection
  • Option 00: 0.0 in unthreaded length
  • Option 80: 8.0 in overall case length
  • Option 10: 1.0 m total system length
  • Option 02: Miniature coaxial ClickLoc connector with standard cable
  • Option 05: Agency approvals including CSA, ATEX, and IECEx for hazardous environments

Applications

  • Turbine and compressor shaft vibration monitoring
  • Rotor axial position measurement
  • Critical rotating machinery protection on 8 mm proximity transducer systems

Ordering Information

Orderable Part Number 330102-00-80-10-02-05 3300 XL 8 mm Proximity Probe, Armored
A - Unthreaded Length 00 0.0 in
B - Case Length 80 8.0 in
C - Total Length 10 1.0 m
D - Connector/Cable 02 Miniature coaxial ClickLoc connector, standard cable
E - Agency Approval 05 CSA, ATEX, IECEx Approvals

Technical Specifications

Manufacturer Bently Nevada
Model 330102
Probe Diameter 8 mm (0.31 in)
Thread 3/8-24 UNF-2A
Cable Type Standard (non-FluidLoc)
Connector Miniature coaxial ClickLoc
Operating Temperature -52 degC to +177 degC (-62 degF to +350 degF)
Agency Approvals CSA, ATEX, IECEx

Installation Guidelines

  • Ensure all connectors are clean and free of debris prior to mating.
  • Finger-tighten ClickLoc connectors securely.
  • Maintain proper probe gap per the specific machinery monitoring configuration requirements.
  • Use appropriate mounting brackets to ensure stability and alignment.
  • Avoid sharp bends or excessive stress on the armored cable during installation.

Compliance and Certifications

  • CSA, ATEX, IECEx Approved
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What does the 80 option code indicate in this part number?
The 80 option code specifies an 8.0 in overall case length for the 330102 probe.
Does this 330102 probe include armor?
Yes, the 330102 series is designed with an integrated stainless steel armor for increased durability against mechanical damage.
Can I use this 1.0 m probe with a 5 m Proximitor sensor?
No, the total system length must match. A 1.0 m probe is designed for use with a 1.0 m system length configuration (typically pairing the probe, extension cable, and Proximitor sensor to equal the total system length).
What type of connector does this probe use?
This probe features a standard Miniature coaxial ClickLoc connector (Option 02).
Reviews

More from this brand

Bently Nevada 168679-01-01-01-02-03-05-01-01-00-02-02 ADRE 408 DSPi Dynamic Signal Processing Instrument
168679-01-01-01-02-03-05-01-01-00-02-02Bently Nevada 168679-01-01-01-02-03-05-01-01-00-02-02 ADRE 408 DSPi Dynamic Signal Processing Instrument
Bently Nevada 3300/50-02-01-00-00 Tachometer Monitor
3300/50-02-01-00-00Bently Nevada 3300/50-02-01-00-00 Tachometer Monitor
Bently Nevada 3300/16-02-01-01-01-00-00 XY/GAP Dual Vibration Monitor
3300/16-02-01-01-01-00-00Bently Nevada 3300/16-02-01-01-01-00-00 XY/GAP Dual Vibration Monitor
Bently Nevada 87890-01 Monitor Circuit Assembly for 3300/03 System Monitor
87890-01Bently Nevada 87890-01 Monitor Circuit Assembly for 3300/03 System Monitor

330102-00-80-10-02-05

Stock & lead time on request

Call
  • Bently Nevada 330102-00-80-10-02-05
  • Bently Nevada 330102-00-80-10-02-05
  • Bently Nevada 330102-00-80-10-02-05
1 3

Bently Nevada 330102-00-80-10-02-05 3300 XL 8 mm Proximity Probe

Only 3 item(s) left in stock

  • Manufacturer: Bently Nevada

  • Product No.: 330102-00-80-10-02-05

  • Country of origin:United States

  • Product Type: 3300 XL 8 mm Proximity Probe

  • Barcode: 8537101190

  • Payment: T/T, Western Union

  • Weight: 140g

  • Dimensions: 45 mm x 95 mm x 95 mm (H x W x D)

  • Shipping port: Xiamen

  • Warranty: 12 months

Visualizza dettagli completi
Product Description
FAQ
Shipping Returns
Additional details
Reviews

Description

330102-00-80-10-02-05: 3300 XL 8 mm proximity probe with armor (Option 80, 8.0 in case length), 1.0 m total length (Option 10), and CSA/ATEX/IECEx approvals (Option 05). This transducer system provides non-contact, eddy-current displacement measurement for critical machinery monitoring, including shaft vibration and axial position applications. The 330102 series includes an integrated protective armor for enhanced mechanical durability in harsh environments. This configuration features a 0.0 in unthreaded length (Option 00) and utilizes the standard Miniature coaxial ClickLoc connector (Option 02) for secure connectivity within 3300 XL monitoring chains.

Features

  • 3300 XL 8 mm proximity probe with armored casing for improved mechanical protection
  • Option 00: 0.0 in unthreaded length
  • Option 80: 8.0 in overall case length
  • Option 10: 1.0 m total system length
  • Option 02: Miniature coaxial ClickLoc connector with standard cable
  • Option 05: Agency approvals including CSA, ATEX, and IECEx for hazardous environments

Applications

  • Turbine and compressor shaft vibration monitoring
  • Rotor axial position measurement
  • Critical rotating machinery protection on 8 mm proximity transducer systems

Ordering Information

Orderable Part Number 330102-00-80-10-02-05 3300 XL 8 mm Proximity Probe, Armored
A - Unthreaded Length 00 0.0 in
B - Case Length 80 8.0 in
C - Total Length 10 1.0 m
D - Connector/Cable 02 Miniature coaxial ClickLoc connector, standard cable
E - Agency Approval 05 CSA, ATEX, IECEx Approvals

Technical Specifications

Manufacturer Bently Nevada
Model 330102
Probe Diameter 8 mm (0.31 in)
Thread 3/8-24 UNF-2A
Cable Type Standard (non-FluidLoc)
Connector Miniature coaxial ClickLoc
Operating Temperature -52 degC to +177 degC (-62 degF to +350 degF)
Agency Approvals CSA, ATEX, IECEx

Installation Guidelines

  • Ensure all connectors are clean and free of debris prior to mating.
  • Finger-tighten ClickLoc connectors securely.
  • Maintain proper probe gap per the specific machinery monitoring configuration requirements.
  • Use appropriate mounting brackets to ensure stability and alignment.
  • Avoid sharp bends or excessive stress on the armored cable during installation.

Compliance and Certifications

  • CSA, ATEX, IECEx Approved
Key Features:
#3300 XL #Proximity Probes

Product Documentation

Technical Datasheet (PDF) Complete specifications and technical drawings.

Technical Datasheet

Bently Nevada 330102-00-80-10-02-05 3300 XL 8 mm Proximity Probe

Download Open in new tab

What does the 80 option code indicate in this part number?
The 80 option code specifies an 8.0 in overall case length for the 330102 probe.

Does this 330102 probe include armor?
Yes, the 330102 series is designed with an integrated stainless steel armor for increased durability against mechanical damage.

Can I use this 1.0 m probe with a 5 m Proximitor sensor?
No, the total system length must match. A 1.0 m probe is designed for use with a 1.0 m system length configuration (typically pairing the probe, extension cable, and Proximitor sensor to equal the total system length).

What type of connector does this probe use?
This probe features a standard Miniature coaxial ClickLoc connector (Option 02).

Global Express Shipping

  • Standard Delivery: 4-6 Business Days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries, including rapid delivery to Saudi Arabia and UAE.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our professional technical warranty.

Orders are processed and delivered Monday-Friday (excluding public holidays).


For full eligibility, restocking fees, and international return details, please view our official Refund & Return Policy .
