Bently Nevada

Bently Nevada 330103-00-12-10-01-00 3300 XL 8 mm Proximity Probe

SKU 330103-00-12-10-01-00

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Bently Nevada
  • Product No.: 330103-00-12-10-01-00
  • Origin United States
  • Product Type: 3300 XL 8 mm Proximity Probe
  • Barcode: 8537101190
  • Payment: T/T, Western Union
  • Weight: 0.14 kg
  • Dimensions: 45 mm x 95 mm x 95 mm (H x W x D)
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

3300 XL Proximity Probes

Product Documentation

Technical Datasheet (PDF) Complete specifications and technical drawings.

Technical Datasheet

Bently Nevada 330103-00-12-10-01-00 3300 XL 8 mm Proximity Probe

Download Open in new tab
Quantità
Call sales Contact

Product Description

Description

The 330103-00-12-10-01-00 is an 8 mm proximity probe from the Bently Nevada 3300 XL series, configured with an M10 x 1 thread (Option 00 unthreaded length, 120 mm case length) and a 1.0-meter system length. This eddy-current transducer is designed for non-contact radial vibration and axial position measurements on critical rotating machinery, such as gas and steam turbines, compressors, and pumps. The probe is engineered for operation within the 3300 XL 8 mm transducer system, which includes a compatible 3300 XL Proximitor sensor and extension cable. This specific configuration features a miniature coaxial ClickLoc connector with a connector protector and standard (unarmored) cable. The absence of armor and the 1.0 m lead make this unit suitable for standard environmental installations where mechanical abrasion protection is not required.

Features

  • M10 x 1 thread size with 120 mm case length (Option 12)
  • 0 mm unthreaded length (Option 00)
  • 1.0 meter total system length (Option 10)
  • Miniature coaxial ClickLoc connector with protector, standard cable (Option 01)
  • Agency Approval: Not required (Option 00)
  • Component of the 3300 XL 8 mm Proximity Transducer System

Applications

  • Shaft vibration and axial position monitoring
  • Rotor position measurement
  • Critical rotating machinery protection
  • Fluid film bearing diagnostics
  • High-speed industrial turbo-machinery

Ordering Information

Option Code on This SKU Description
Orderable Part Number 330103-00-12-10-01-00 3300 XL 8 mm Probe, M10 x 1, without armor
A - Unthreaded Length 00 0 mm unthreaded length
B - Case Length 12 120 mm case length
C - Total Length 10 1.0 meter system length
D - Connector/Cable 01 ClickLoc connector with connector protector, standard cable
E - Agency Approval 00 Not required

Technical Specifications

Manufacturer Bently Nevada (Baker Hughes)
Part Number 330103-00-12-10-01-00
Probe Diameter 8.0 mm
Thread Size M10 x 1
Cable Type Standard (unarmored) coaxial
Connector Miniature coaxial ClickLoc with connector protector
System Length 1.0 m
Operating Temperature -52 degC to +177 degC
Material AISI 303 or 304 Stainless Steel
Agency Approvals Not required

Installation Guidelines

  • Ensure the probe tip is installed in a rigid, non-conductive mount if electrical isolation is required.
  • Maintain the specified gap voltage requirements as defined in the 3300 XL monitoring system manual.
  • Tighten ClickLoc connectors finger-tight; do not use pliers or tools to force the connection.
  • Ensure the cable is routed away from high-voltage lines to prevent electromagnetic interference (EMI).
  • For probes with M10 x 1 threads, do not exceed 15 mm of thread engagement to prevent binding.

Compliance and Certifications

  • CE marked
  • RoHS compliant
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What does the 00 code for unthreaded length mean for this 330103 probe?
The 00 option indicates that the probe has 0 mm of unthreaded length, meaning the probe threading extends to the base of the probe tip housing.
Is this probe compatible with armored extension cables?
No, this SKU (Option 01) is configured for standard, unarmored cabling. If you require abrasion protection, you should select a probe configured with armor (e.g., 330104 series).
Can I use this 1.0 m probe with a 5.0 m extension cable?
Yes, the 3300 XL 8 mm system is designed to maintain a consistent total system length (probe + extension cable) of 5.0 meters or 9.0 meters. Using a 1.0 m probe with a 4.0 m extension cable (total 5 m) is a standard configuration.
What is the tightening torque for the ClickLoc connector?
The ClickLoc connector should be tightened finger-tight only. Do not use pliers or mechanical tools, as this can damage the connector and signal integrity.
