The 330103-00-05-50-12-00 is an 8 mm proximity probe configuration from the Bently Nevada 3300 XL transducer system. This unit features an M10 x 1 threaded probe body (Option 00 unthreaded length, Option 05 case length) and a 5.0 meter total system length (Option 50). The probe is equipped with a miniature coaxial ClickLoc connector and FluidLoc cable (Option 12), ensuring reliable, non-contact eddy-current displacement measurement for critical rotating machinery.
Designed for integration into 3300 XL monitoring chains, this probe pairs with the 3300 XL Proximitor sensor and extension cable to provide continuous shaft vibration and axial position monitoring. The M10 x 1 thread and FluidLoc cable construction make this specific variant suitable for installations requiring sealing against fluid migration along the cable path. As a non-hazardous area configuration (Option 00 agency approval), this probe is ideal for standard industrial environments.
| Option | Code on This SKU | Description |
|---|---|---|
| Orderable Part Number | 330103-00-05-50-12-00 | 3300 XL 8 mm Proximity Probe, M10 x 1 |
| A - Unthreaded Length | 00 | 0.0 in unthreaded length |
| B - Case Length | 05 | 0.5 in case length |
| C - Total Length | 50 | 5.0 meters total system length |
| D - Connector/Cable | 12 | Miniature coaxial ClickLoc connector, FluidLoc cable |
| E - Agency Approval | 00 | Not required |
| Manufacturer | Bently Nevada (Baker Hughes) |
| Part Number | 330103-00-05-50-12-00 |
| System | 3300 XL 8 mm Proximity Transducer System |
| Probe Diameter | 8 mm |
| Thread | M10 x 1 |
| Total Length | 5.0 m |
| Connector | Miniature coaxial ClickLoc |
| Cable Type | FluidLoc |
| Agency Approval | Not required (Standard) |
| Temperature Range | -55 degC to +177 degC (Probe tip) |
Ensure the probe is gapped according to the 3300 XL system manual. When installing probes with FluidLoc cables, avoid sharp bends near the connector to maintain cable integrity. For mounting, use the appropriate M10 x 1 compatible mounting brackets. Ensure the total system length (probe + extension cable) matches the calibrated Proximitor sensor length (5.0 m).
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 330103-00-05-50-12-00
Country of origin:United States
Product Type: 3300 XL 8 mm Proximity Probe
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 140g
Dimensions: 45 mm x 95 mm x 95 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months
