Option 065 (6.5 m cable length) and Option 04 (stainless steel armor with FEP jacket and connector protector) specify this 3300 NSv extension cable configuration — 330930-065-04-00. This coaxial extension cable is part of the 3300 XL NSv proximity transducer system, which is used for non-contact displacement, vibration, and position measurements where target geometry is restricted or installation clearances are tight.
This cable configuration provides physical armor protection for demanding industrial environments. The integrated stainless steel armor prevents mechanical wear and abrasion, while the outer FEP jacket shields the cable from fluid exposure, moisture, and chemical degradation. Additionally, the pre-installed connector protector shields the male and female miniature ClickLoc connectors against ingress. This cable links a compatible 3300 NSv proximity probe to a 330980 Proximitor sensor, completing a 7.0-meter system length when paired with a 0.5-meter probe.
| Option | Code on This SKU | Description |
|---|---|---|
| Orderable Part Number | 330930-065-04-00 | 3300 NSv Extension Cable, 3300 XL NSv System |
| A - Cable Length Option | 065 | 6.5 meters (21.3 feet) |
| B - Connector and Cable Option | 04 | With stainless steel armor, with FEP jacket, with connector protector |
| C - Agency Approval Option | 00 | Agency approval not required |
| Manufacturer | Bently Nevada (Baker Hughes) |
| Part Number | 330930-065-04-00 |
| Product Series | 3300 XL NSv Proximity Transducer System |
| Cable Length | 6.5 m (21.3 ft) |
| Cable Impedance | 75 ohms nominal |
| Armor Construction | Stainless steel armor with protective fluorinated ethylene propylene (FEP) jacket |
| Connector Protection | Included connector protector on coaxial joint |
| Minimum Bend Radius | 25.4 mm (1.0 in) |
| Center Conductor Resistance | 0.220 ohms per meter (0.067 ohms per foot) |
| Shield DC Resistance | 0.066 ohms per meter (0.020 ohms per foot) |
| Cable Capacitance | 69.9 pF per meter (21.3 pF per foot) typical |
| Connection Types | Miniature coaxial ClickLoc connectors (male and female) |
| Connector Pull Strength | Maximum rated pull force of 220 N (50 lb) |
| Operating and Storage Temperature | -52 degC to +177 degC (-62 degF to +351 degF) |
| Relative Humidity Limit | 100% condensing, non-submersible (with protected connectors) |
Ensure that the sum of the extension cable length and the probe length matches the total calibration length of the Proximitor sensor (for example, a 6.5 m extension cable paired with a 0.5 m probe completes a 7.0 m system). Maintain a minimum bend radius of 25.4 mm (1.0 in) along the entire run of the armored cable. Hand-tighten the miniature coaxial ClickLoc connectors to complete the connection, and verify that the connector protector is fully seated over the joint to prevent moisture ingress. Use cable clamps or protective conduit to secure the armored jacket within the machine enclosure to prevent whipping or friction damage in high-vibration areas.
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 330930-065-04-00
Country of origin:United States
Product Type: 3300 NSv Extension Cable
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 120g
Dimensions: 45 mm x 90 mm x 90 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months
