Bently Nevada

Bently Nevada 330103-00-12-10-02-CN 3300 XL 8 mm Proximity Probe

SKU 330103-00-12-10-02-CN

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Bently Nevada
  • Product No.: 330103-00-12-10-02-CN
  • Origin United States
  • Product Type: 3300 XL 8 mm Proximity Probe
  • Barcode: 8537101190
  • Payment: T/T, Western Union
  • Weight: 0.14 kg
  • Dimensions: 45 mm x 95 mm x 95 mm (H x W x D)
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

3300 XL Proximity Probes

Product Documentation

Technical Datasheet (PDF) Complete specifications and technical drawings.

Technical Datasheet

Bently Nevada 330103-00-12-10-02-CN 3300 XL 8 mm Proximity Probe

Download Open in new tab
Quantità
Call sales Contact

Product Description

Description

The 330103-00-12-10-02-CN is an 8 mm 3300 XL proximity probe designed for seamless integration into 3300 XL 8 mm proximity transducer systems. This configuration features Option 00 (0.0 in unthreaded length), Option 12 (1.2 in case length), Option 10 (1.0 m total length), and Option 02 (Miniature ClickLoc connector). The -CN suffix indicates a specialized China hazardous area approval package, including NEPSI and CCC certifications required for compliance in regional industrial installations.

This eddy-current probe is utilized for measuring shaft vibration and axial position on critical rotating machinery. It operates as part of a complete transducer chain, which includes a 330180 Proximitor sensor and a 330130 extension cable. The system is engineered for reliable, non-contact performance in harsh environments, provided that proper installation and grounding practices are followed to maintain signal integrity.

Features

  • Option 00: 0.0 in unthreaded length
  • Option 12: 1.2 in case length
  • Option 10: 1.0 m total length
  • Option 02: Miniature ClickLoc connector, standard cable
  • Suffix -CN: China hazardous area approval package (NEPSI + CCC)
  • Standard 3/8-24 UNF threads for mounting
  • Compatible with 3300 XL 8 mm Proximitor sensors and extension cables

Applications

  • Steam and gas turbine generator sets
  • Centrifugal compressors and blowers
  • Large electric motors and pumps
  • Rotating machinery shaft vibration and rotor position monitoring
  • Fluid film bearing and journal bearing applications

Ordering Information

Option Code Description
Orderable Part Number 330103-00-12-10-02-CN 3300 XL 8 mm Proximity Probe
A - Unthreaded Length 00 0.0 in
B - Case Length 12 1.2 in
C - Total Length 10 1.0 m
D - Connector 02 Miniature ClickLoc, standard cable
Suffix -CN China hazardous area approval package

Technical Specifications

Manufacturer Bently Nevada
Part Number 330103-00-12-10-02-CN
Probe Diameter 8 mm
Mounting Thread 3/8-24 UNF
Linear Range 2 mm (80 mils)
Temperature Range (Operating) -51 degC to +177 degC
Case Material AISI 303 or 304 stainless steel
Connection Type Miniature ClickLoc

Installation Guidelines

  • Ensure the probe is mounted in a rigid, non-conductive bracket if necessary to prevent ground loops.
  • Maintain the specified probe gap as defined in the system documentation for linear operation.
  • Protect the connector from moisture and contaminants using the appropriate connector protector or by installing in a dry environment.
  • Route coaxial extension cables away from high-voltage AC lines to minimize electromagnetic interference.

Compliance and Certifications

  • NEPSI (China hazardous area approval)
  • CCC (China Compulsory Certification)
  • Compliant with 3300 XL system requirements
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What does the -CN suffix mean for this Bently Nevada probe?
The -CN suffix denotes that this specific probe is certified with a China hazardous area approval package, which includes NEPSI and CCC certifications.
Is this probe compatible with standard 3300 XL extension cables?
Yes, this probe uses the standard 330130 series extension cable and the 330180 series Proximitor sensor for complete 3300 XL transducer system functionality.
What is the total length of this probe configuration?
This specific part number (330103-00-12-10-02-CN) includes a 1.0 meter total system length, as specified by the Option 10 segment.
Does this probe include a connector protector?
Option 02 indicates a Miniature ClickLoc connector without a connector protector. If your application requires extra protection, please ensure the installation environment is suitable or that external protection is added.
