The 330103-01-06-05-02-00 is a 3300 XL 8 mm proximity probe configuration featuring an M10 x 1 thread, 0.1 in unthreaded length (Option 01), 0.6 in case length (Option 06), 0.5 meter total length (Option 05), standard connector (Option 02), and no agency approvals (Option 00). This probe is designed for non-contact eddy-current displacement measurement within 3300 XL monitoring chains, providing precise shaft vibration and axial position data for critical rotating machinery.
This model is part of the 3300 XL 8 mm transducer family and operates seamlessly with the 330180 Proximitor sensor and 330130 extension cable. The standard connector configuration (Option 02) provides reliable signal transmission for machinery protection applications in non-hazardous environments. Its M10 x 1 thread design facilitates installation in standardized metric mounting locations common in industrial turbomachinery.
| Option | Code | Description |
|---|---|---|
| Orderable Part Number | 330103-01-06-05-02-00 | 3300 XL 8 mm Proximity Probe, M10 x 1 |
| A - Unthreaded Length | 01 | 0.1 in |
| B - Case Length | 06 | 0.6 in |
| C - Total Length | 05 | 0.5 meter |
| D - Connector | 02 | Miniature coaxial ClickLoc connector, standard cable |
| E - Agency Approval | 00 | Not required |
| Parameter | Specification |
|---|---|
| Manufacturer | Bently Nevada |
| Model | 330103 |
| Probe Diameter | 8 mm |
| Thread Size | M10 x 1 |
| Cable Type | Standard |
| Connector | Miniature coaxial ClickLoc |
| Total Length | 0.5 meter |
| Agency Approvals | Not required |
Ensure the probe is gapped according to the specific 3300 XL system documentation. Use compatible mounting brackets to avoid electrical interference. Ensure all cable connections are tightened to the ClickLoc standard and protected from excessive vibration or fluid ingress where applicable.
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 330103-01-06-05-02-00
Country of origin:United States
Product Type: 3300 XL 8 mm Proximity Probe
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 140g
Dimensions: 45 mm x 95 mm x 95 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months
