The 330103-00-07-05-02-00 is an 8 mm proximity probe from the Bently Nevada 3300 XL transducer system, configured with an M10 x 1 thread (Option 04 base type), 0.0 in unthreaded length (Option 00), 0.7 in case length (Option 07), and a 0.5 meter total length (Option 05). This non-contact eddy-current displacement probe is designed for use in critical machinery monitoring applications, specifically for measuring shaft vibration and axial position on rotating equipment.
This configuration features a miniature coaxial ClickLoc connector with standard cable (Option 02) and no required agency approvals (Option 00). As part of the 3300 XL series, it provides advanced measurement accuracy and environmental robustness when paired with a compatible 3300 XL Proximitor sensor and extension cable. The M10 x 1 threaded body allows for precise mounting in machinery cases, while the 0.5 meter lead length is optimized for installations where the Proximitor sensor is located in close proximity to the measurement point.
| Option | Code on This SKU | Description |
|---|---|---|
| Orderable Part Number | 330103-00-07-05-02-00 | 3300 XL 8 mm Proximity Probe, M10 x 1 |
| A - Unthreaded Length | 00 | 0.0 in (per datasheet specs) |
| B - Case Length | 07 | 0.7 in (per datasheet specs) |
| C - Total Length | 05 | 0.5 meter (1.6 feet) |
| D - Connector/Cable | 02 | Miniature coaxial ClickLoc, standard cable |
| E - Agency Approval | 00 | Not required |
| Manufacturer | Bently Nevada (Baker Hughes) |
| Part Number | 330103-00-07-05-02-00 |
| Probe Diameter | 8 mm |
| Thread Size | M10 x 1 |
| Total Length | 0.5 m |
| Connector Type | Miniature coaxial ClickLoc |
| Cable Type | Standard |
| Agency Approvals | Not required (Option 00) |
| System Compatibility | 3300 XL 8 mm Proximitor Sensor and Extension Cable |
Ensure that the probe is mounted using the appropriate threaded bracket. When installing, verify the probe gap according to the system manual (141078) to maintain the linear range of the transducer. The ClickLoc connector should be tightened until the internal mechanism clicks, ensuring proper mechanical connection without over-torquing. Proper cable routing and shielding are essential to minimize electromagnetic interference. Avoid excessive bending of the coaxial cable to prevent impedance changes.
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 330103-00-07-05-02-00
Country of origin:United States
Product Type: 3300 XL 8 mm Proximity Probe
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 140g
Dimensions: 45 mm x 95 mm x 95 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months
