The 330103-06-10-10-02-05 is a 3300 XL 8 mm proximity probe configured with an M10 x 1 thread and unarmored construction. This specific unit features a 60 mm unthreaded length (Option 06) and a 100 mm total case length (Option 10), providing the necessary mechanical dimensions for precise shaft position and vibration monitoring in critical rotating machinery. Designed for integration within 3300 XL monitoring systems, this probe utilizes a 1.0 meter total system length (Option 10) and is equipped with a miniature coaxial ClickLoc connector on a standard cable (Option 02).
This 3300 XL probe configuration supports hazardous area installations, carrying CSA, ATEX, and IECEx approvals (Option 05). It is compatible with 3300 XL Proximitor sensors and extension cables, forming a complete eddy-current displacement transducer system used to measure radial vibration, axial position, and speed on turbines, compressors, and large electric motors.
| Option | Code on This SKU | Description |
|---|---|---|
| Orderable Part Number | 330103-06-10-10-02-05 | 3300 XL 8 mm Proximity Probe, M10 x 1 |
| A - Unthreaded Length | 06 | 60 mm |
| B - Case Length | 10 | 100 mm |
| C - Total Length | 10 | 1.0 meter (3.3 feet) |
| D - Connector/Cable | 02 | Miniature ClickLoc, standard cable |
| E - Agency Approval | 05 | CSA, ATEX, IECEx Approvals |
| Parameter | Specification |
|---|---|
| Manufacturer | Bently Nevada |
| Part Number | 330103-06-10-10-02-05 |
| Probe Diameter | 8.0 mm |
| Thread Size | M10 x 1 |
| Cable Type | Standard cable, miniature coaxial ClickLoc |
| Total Length | 1.0 meter |
| Mounting | M10 x 1 thread (unarmored) |
| Approvals | CSA, ATEX, IECEx |
Ensure the probe is gapped correctly according to the 3300 XL system manual to maintain linear measurement ranges. Keep cable connections clean and dry during installation; the ClickLoc connector should be torqued to manufacturer specifications. Ensure the extension cable and probe lead lengths combine to equal the calibrated length required by the Proximitor sensor. Use appropriate conduits or shielding if the installation environment includes significant electromagnetic interference or high vibration.
This product meets global hazardous area standards, including CSA, ATEX, and IECEx certifications (Option 05), permitting installation in designated hazardous locations.
