330104-06-25-05-02-00 is an 8 mm 3300 XL proximity probe configuration featuring an M10 x 1 thread, 60 mm unthreaded length (Option 06), and a 250 mm case length (Option 25). This non-contact, eddy-current transducer is engineered for measuring shaft vibration and axial position on critical rotating machinery. The probe utilizes a standard miniature ClickLoc coaxial connector (Option 02) and is supplied without hazardous area approvals (Option 00).
This transducer is designed to be used as a matched system with 3300 XL components, including the 330180 Proximitor sensor and 330130 extension cable. The assembly includes armor protection for the cable to ensure durability in harsh industrial environments. Proper system length matching (0.5 meter total system length) is critical for accurate signal conditioning and linear output in monitoring applications.
| Option | Code on This SKU | Description |
|---|---|---|
| Orderable Part Number | 330104-06-25-05-02-00 | 3300 XL 8 mm Proximity Probe, M10 x 1 thread |
| A - Unthreaded Length | 06 | 60 mm |
| B - Case Length | 25 | 250 mm |
| C - Total Length | 05 | 0.5 meter (1.6 feet) |
| D - Connector/Cable | 02 | Miniature ClickLoc connector, standard cable |
| E - Agency Approval | 00 | Not required |
| Parameter | Specification |
|---|---|
| Manufacturer | Bently Nevada (Baker Hughes) |
| Part Number | 330104-06-25-05-02-00 |
| Probe Type | 3300 XL 8 mm Proximity Probe |
| Thread Size | M10 x 1 |
| Unthreaded Length | 60 mm |
| Case Length | 250 mm |
| Total System Length | 0.5 meter |
| Cable Type | Standard cable with armor |
| Connector Type | Miniature ClickLoc coaxial |
| Agency Approvals | Not required |
Ensure the probe is mounted using the compatible M10 x 1 threaded mounting bracket. Maintain the recommended gap voltage (typically -10V DC at mid-range) during installation for accurate operation. When routing the armored cable, avoid sharp bends and ensure the cable is secured to prevent vibration-induced fatigue. Ensure the system length (probe + extension cable) matches the calibrated Proximitor sensor length (0.5 meter total in this configuration).
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 330104-06-25-05-02-00
Country of origin:United States
Product Type: 3300 XL 8 mm Proximity Probe
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 140g
Dimensions: 45 mm x 95 mm x 95 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months
