Bently Nevada

Bently Nevada 330103-06-13-05-02-CN 3300 XL 8 mm Proximity Probe

SKU 330103-06-13-05-02-CN

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Bently Nevada
  • Product No.: 330103-06-13-05-02-CN
  • Origin United States
  • Product Type: 3300 XL 8 mm Proximity Probe
  • Barcode: 8537101190
  • Payment: T/T, Western Union
  • Weight: 0.14 kg
  • Dimensions: 45 mm x 95 mm x 95 mm (H x W x D)
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

3300 XL Proximity Probes

Product Documentation

Technical Datasheet (PDF) Complete specifications and technical drawings.

Technical Datasheet

Bently Nevada 330103-06-13-05-02-CN 3300 XL 8 mm Proximity Probe

Download Open in new tab
Quantità
Call sales Contact

Product Description

Description

The 330103-06-13-05-02-CN is a 3300 XL 8 mm proximity probe engineered for non-contact eddy-current displacement measurement in critical rotating machinery. This specific configuration features an M10 x 1 thread (unarmored) with a 60 mm unthreaded length (Option 06) and a 130 mm total case length (Option 13). It is designed to pair with 3300 XL Proximitor sensors and extension cables as part of a calibrated monitoring chain for shaft vibration and axial position applications.

This probe utilizes a 0.5 meter (Option 05) integral lead with a miniature coaxial ClickLoc connector (Option 02). The -CN suffix indicates this unit includes a China hazardous area approval package (NEPSI and CCC compliance). It is suitable for use in demanding industrial environments such as power generation, oil and gas, and petrochemical processing where precise rotor-to-stator gap measurements are required.

Features

  • M10 x 1 thread, unarmored 3300 XL 8 mm probe body
  • Option 06: 60 mm unthreaded length
  • Option 13: 130 mm total case length
  • Option 05: 0.5 meter (1.6 feet) probe lead length
  • Option 02: Miniature coaxial ClickLoc connector with standard cable
  • -CN suffix: Includes China hazardous area approval package (NEPSI and CCC)
  • Compatible with 3300 XL Proximitor sensor and 3300 XL extension cable systems

Applications

  • Turbine and compressor shaft vibration monitoring
  • Rotor axial position and displacement measurement
  • Critical rotating machinery protection
  • Fluid-film bearing monitoring

Ordering Information

Option Code Description
Orderable Part Number 330103-06-13-05-02-CN 3300 XL 8 mm Proximity Probe, M10 x 1, Unarmored
A - Unthreaded Length 06 60 mm unthreaded length
B - Case Length 13 130 mm total case length
C - Total Length 05 0.5 meter (1.6 feet)
D - Connector/Cable 02 Miniature coaxial ClickLoc connector, standard cable
Suffix -CN China hazardous area approval (NEPSI + CCC)

Technical Specifications

Manufacturer Bently Nevada
Part Number 330103-06-13-05-02-CN
Probe Diameter 8 mm
Thread Size M10 x 1
Probe Type Unarmored
Connector Type Miniature coaxial ClickLoc
Cable Length 0.5 m
Temperature Range -51 degC to +177 degC
Compliance NEPSI, CCC (per -CN suffix)

Installation Guidelines

  • Ensure the probe gap is set according to the 3300 XL system manual for the target material.
  • Route probe leads away from high-voltage cables and potential interference sources.
  • Use the appropriate threaded mounting bracket (M10 x 1) to secure the probe, ensuring it is locked in place with the provided jam nut.
  • Maintain the integrity of the ClickLoc connector by keeping it free of contaminants during installation.
  • Ensure the total system length (Probe + Extension Cable) matches the calibration of the Proximitor sensor (e.g., 5-meter or 9-meter system).

Compliance and Certifications

  • NEPSI (China)
  • CCC (China)
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
Che cosa significa il suffisso -CN per questo codice articolo?
Il suffisso -CN indica che questa sonda è dotata del pacchetto di omologazioni per aree pericolose in Cina, che include le certificazioni NEPSI e CCC richieste per l'impiego nei mercati industriali cinesi.
La sonda 330103 è corazzata?
No, la 330103 è una sonda di prossimità 3300 XL standard, non corazzata, da 8 mm, con filettatura M10 x 1.
Questa sonda può essere utilizzata con un sensore Proximitor da 9 metri?
No, questa sonda ha un cavo integrato da 0,5 metri ed è progettata per essere utilizzata con un sistema di monitoraggio da 5 metri. La lunghezza totale della sonda e del cavo di prolunga deve corrispondere alla lunghezza calibrata del sensore Proximitor.
Quale tipo di connettore utilizza questa sonda?
Questa configurazione utilizza il connettore coassiale miniaturizzato ClickLoc, specificato dall'Opzione 02.
