330105-02-12-90-02-05 is a 3300 XL 8 mm reverse mount proximity probe, featuring a 3/8-24 UNF thread, 20 mm unthreaded length (Option 02), and 120 mm case length (Option 12). This 3300 XL 8 mm proximity probe is engineered for non-contact eddy-current displacement measurement, serving as a core component in vibration and position monitoring systems for critical rotating machinery. The system provides a precise voltage output proportional to the gap between the probe tip and the observed conductive surface, essential for monitoring shaft vibration, axial position, and rotor speed in turbines, compressors, and pumps.
This configuration includes a 9.0 meter total system length (Option 90) and uses a miniature coaxial ClickLoc connector with a standard cable (Option 02). It is rated for hazardous area environments with CSA, ATEX, and IECEx approvals (Option 05). The 3300 XL design ensures compatibility with 3300 XL Proximitor sensors and extension cables, maintaining the necessary electrical impedance match for reliable, long-term performance in industrial monitoring applications.
| Option | Code on This SKU | Description |
|---|---|---|
| Orderable Part Number | 330105-02-12-90-02-05 | 3300 XL 8 mm Reverse Mount Probe |
| A - Unthreaded Length | 02 | 20 mm |
| B - Case Length | 12 | 120 mm |
| C - Total Length | 90 | 9.0 meters (29.5 feet) |
| D - Connector/Cable | 02 | Miniature ClickLoc, standard cable |
| E - Agency Approval | 05 | CSA, ATEX, IECEx Approvals |
| Manufacturer | Bently Nevada (Baker Hughes) |
| Part Number | 330105-02-12-90-02-05 |
| Product Type | 3300 XL 8 mm Reverse Mount Probe |
| Thread Size | 3/8-24 UNF-2A |
| Probe Tip Diameter | 8.0 mm (0.31 in) |
| Total System Length | 9.0 meters |
| Connector Type | Miniature ClickLoc coaxial |
| Cable Type | Standard coaxial cable |
| Agency Approvals | CSA, ATEX, IECEx |
| Operating Temperature | -55 degC to +177 degC (Probe tip dependent) |
Ensure the probe is installed using the appropriate mounting hardware for 3/8-24 UNF threads. Maintain proper gap settings as specified in the 3300 XL manual to ensure linear operation. The miniature ClickLoc connector must be clean and free of moisture during installation. When routing cables, avoid sharp bends and ensure the cable length and probe length match the system calibration (9.0 m total length in this configuration). In hazardous area installations, ensure compliance with the provided Bently Nevada drawing 141092 or 140979 as applicable.
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 330105-02-12-90-02-05
Country of origin:United States
Product Type: Sonde con montaggio inverso da 8 mm 3300 XL
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 140g
Dimensions: 45 mm x 95 mm x 95 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months
