Bently Nevada

Bently Nevada 330130-080-01-00 3300 XL 8 mm Proximity Transducer System Extension Cable

SKU 330130-080-01-00

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Bently Nevada
  • Product No.: 330130-080-01-00
  • Origin United States
  • Product Type: 3300 XL Standard Extension Cable
  • Barcode: 8537101190
  • Payment: T/T, Western Union
  • Weight: 0.14 kg
  • Dimensions: 45 mm x 95 mm x 95 mm (H x W x D)
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

3300 XL Extension Cables

Product Documentation

Technical Datasheet (PDF) Complete specifications and technical drawings.

Technical Datasheet

Bently Nevada 330130-080-01-00 3300 XL 8 mm Proximity Transducer System Extension Cable

Download Open in new tab
Quantità
Call sales Contact

Product Description

Description

330130-080-01-00 is an 8.0-meter 3300 XL standard extension cable designed for integration with Bently Nevada 3300 XL 8 mm proximity transducer systems. This specific configuration features armored cabling (Option 01) to provide mechanical protection in industrial environments, ensuring reliable signal transmission between the proximity probe and the Proximitor sensor. This extension cable does not include agency approval (Option 00).

The 3300 XL system uses coaxial ClickLoc connectors to connect the probe, extension cable, and Proximitor sensor. Proper system calibration requires that the probe length plus the extension cable length equals the total system length specified for the Proximitor sensor. This armored cable is built for harsh conditions where abrasion resistance is required, maintaining the integrity of the eddy-current displacement measurements used for critical machinery monitoring, such as shaft vibration and axial position.

Features

  • 8.0 meters (26.2 feet) total length
  • Armored cable construction for improved mechanical abrasion resistance
  • Standard ClickLoc coaxial connectors for consistent, reliable connections
  • Compatible with 3300 XL 8 mm proximity probes and 3300 XL Proximitor sensors
  • Option 00 agency approval: not required

Applications

  • Critical rotating machinery protection
  • Turbine and compressor shaft vibration monitoring
  • Rotor axial position measurement
  • Industrial environments requiring armored cable protection
  • Fluid machinery and power generation assets

Ordering Information

Option Code on This SKU Description
Orderable Part Number 330130-080-01-00 3300 XL 8 mm Extension Cable
A - Cable Length 080 8.0 meters (26.2 feet)
B - Cable Option 01 Armored cable
C - Agency Approval 00 Not required

Technical Specifications

Parameter Specification
Manufacturer Bently Nevada
Part Number 330130-080-01-00
Cable Type Standard extension cable, armored
Total Length 8.0 meters (26.2 feet)
Connector Type Miniature coaxial ClickLoc
System Compatibility 3300 XL 8 mm Proximity Transducer System
Agency Approval None (Not required)

Installation Guidelines

  • Ensure that the total system length (Probe + Extension Cable) matches the Proximitor sensor rating.
  • Avoid sharp bends in the cable; maintain the minimum bend radius to prevent damage to the coaxial core.
  • Use appropriate connector protectors if the environment exposes connections to moisture or contaminants.
  • Route cables away from high-voltage power lines to minimize electromagnetic interference.
  • Secure armored cables using suitable clamps to prevent vibration-induced wear.
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What does the '01' option code mean for this 330130 cable?
The '01' option code specifies that this extension cable is armored, providing additional mechanical protection against abrasion in industrial settings.
Is this extension cable compatible with my 3300 XL 8 mm probe?
Yes, the 330130 extension cable is designed specifically for the 3300 XL 8 mm proximity transducer system.
Can I use this 8.0-meter cable with any Proximitor sensor?
The total system length (probe plus extension cable) must match the requirements of the Proximitor sensor. Ensure your configuration aligns with the Proximitor sensor's total system length rating.
