The 330130-080-01-05 is a 3300 XL Standard Extension Cable designed for use within 3300 XL 8 mm proximity transducer monitoring chains. This specific configuration features an 8.0-meter cable length (Option 080), standard cable construction (Option 01), and CSA, ATEX, and IECEx agency approvals (Option 05). It facilitates the connection between a 3300 XL proximity probe and a 3300 XL Proximitor sensor, ensuring signal integrity in critical machinery monitoring applications such as shaft vibration and axial position measurement.
The 3300 XL extension cable system is engineered for harsh industrial environments, providing reliable performance in turbomachinery protection systems. When selecting extension cables, ensure the total system length—comprising the probe, extension cable, and Proximitor sensor—matches the calibrated 5-meter or 9-meter system requirement. This standard cable version provides robust, non-armored connectivity suitable for standard industrial installations where physical abrasion protection is not required.
| Option | Code on This SKU | Description |
|---|---|---|
| Orderable Part Number | 330130-080-01-05 | 3300 XL Standard Extension Cable |
| A - Cable Length | 080 | 8.0 meters (26.2 feet) |
| B - Cable Option | 01 | Standard cable (non-armored) |
| C - Agency Approval | 05 | CSA, ATEX, IECEx Approvals |
| Parameter | Specification |
|---|---|
| Manufacturer | Bently Nevada (Baker Hughes) |
| Part Number | 330130-080-01-05 |
| Cable Length | 8.0 meters |
| Cable Type | Standard (Non-armored) |
| Connector Type | Miniature coaxial ClickLoc |
| Agency Approvals | CSA, ATEX, IECEx |
| Temperature Range | -51 degC to +177 degC (Storage/Operating) |
Ensure that the total length of the probe and extension cable combined matches the requirements of the Proximitor sensor (e.g., 5-meter or 9-meter systems). When installing, maintain proper bend radii to prevent cable damage. In hazardous areas, ensure the installation complies with all local and international codes as specified by the agency approvals. Protect connectors from contamination and ensure the ClickLoc connectors are fully engaged.
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 330130-080-01-05
Country of origin:United States
Product Type: 3300 XL Standard Extension Cable
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 140g
Dimensions: 45 mm x 95 mm x 95 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months
