330130-080-01-CN specifies this 3300 XL standard extension cable configured with an 8.0 m length, armored mechanical protection, and a China-specific NEPSI/CCC hazardous area certification package.
Unlike standard unarmored configurations, this cable includes a flexible AISI 302 or 304 stainless steel armor with an outer FEP jacket that protects the internal triaxial conductor from mechanical damage and abrasive wear. The 8.0-meter length is typically selected to build a 9.0-meter total system length when combined with a standard 1.0-meter proximity probe, or a 10.0-meter total length system in specialized layouts. The trailing -CN suffix adds official CCC and NEPSI explosion-proof certifications required for hazardous industrial plant operations across China.
Common industrial applications for this extension cable include monitoring steam and gas turbine shaft vibration, monitoring compressor axial position, monitoring industrial pump rotor displacement, and implementing machine protection systems on large rotating machinery in hazardous chemical or petrochemical processing environments.
| Option/Segment | Code on This SKU | Description |
|---|---|---|
| Orderable Part Number | 330130-080-01-CN | 3300 XL Standard Extension Cable, armored, with China approval package |
| A - Cable Length Option | 080 | 8.0 meters (26.2 feet) |
| B - Connector Protector and Cable Option | 01 | Armored cable (Flexible AISI 302 or 304 SST with FEP outer jacket) |
| Suffix | -CN | China hazardous area approval package (NEPSI + CCC + applicable markings) |
| Parameter | Specification Value |
|---|---|
| Manufacturer | Bently Nevada (Baker Hughes) |
| Model / Part Number | 330130-080-01-CN |
| Product Type | Standard Extension Cable (Armored) |
| Cable Length | 8.0 meters (26.2 feet) |
| Cable Type | 75 Ohm triaxial, FEP insulated |
| Armor Construction | Flexible AISI 302 or 304 SST with FEP outer jacket |
| Cable Outside Diameter | 3.7 mm maximum (non-armored section) |
| Armor Outside Diameter | 7.67 mm maximum |
| Armor Ferrule Diameter | 10.2 mm maximum |
| Minimum Bend Radius | 25.4 mm (1.0 in) |
| Operating Temperature Range | -52 degC to +177 degC (-62 degF to +350 degF) |
| Storage Temperature Range | -52 degC to +177 degC (-62 degF to +350 degF) |
| Tensile Strength | 330 N (75 lbf) probe case to probe lead; 270 N (60 lbf) at connectors |
| Connector Type | Gold-plated coaxial ClickLoc connectors |
| Weight | 0.82 kg |
| Dimensions | 250 mm x 250 mm x 40 mm (H x W x D) |
During installation, ensure the minimum bend radius of 25.4 mm is not exceeded to avoid degrading the triaxial insulation. When joining the ClickLoc connectors, tighten them finger tight; do not use pliers unless connecting non-XL stainless steel components. Use appropriate conduit or cable trays to route the armored section. Ensure that all shield and ground connections are properly terminated at the Proximitor sensor terminal strip to prevent external electrical noise interference.
| Certification Body | Approved Rating / Package |
|---|---|
| CCC | China Compulsory Certificate for explosive environments |
| NEPSI | National Supervision and Inspection Centre for Explosion Protection (China) |
| CE | European conformity |
| RoHS | Directive 2011/65/EU compliant |
| Functional Safety | SIL 2 / SIL 3 capable systems |
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 330130-080-01-CN
Country of origin:United States
Product Type: 3300 XL Standard Extension Cable
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 820g
Dimensions: 250 mm x 250 mm x 40 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months
