Bently Nevada 330130-085-01-00 3300 XL Standard Extension Cable

SKU 330130-085-01-00

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Bently Nevada
  • Product No.: 330130-085-01-00
  • Origin United States
  • Product Type: 3300 XL Standard Extension Cable
  • Barcode: 8537101190
  • Payment: T/T, Western Union
  • Weight: 0.88 kg
  • Dimensions: 250 mm x 250 mm x 40 mm (H x W x D)
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

3300 XL Standard Extension Cables

Product Documentation

Technical Datasheet (PDF) Complete specifications and technical drawings.

Technical Datasheet

Bently Nevada 330130-085-01-00 3300 XL Standard Extension Cable

Download Open in new tab
Quantità
Call sales Contact

Product Description

Description

330130-085-01-00: This 3300 XL Standard Extension Cable features an 8.5-meter cable length (Option 085) and integrated stainless steel armor (Option 01) without agency approvals (Option 00). It is used to connect 3300 XL 8 mm proximity probes to a 3300 XL Proximitor Sensor, completing the transmission path for eddy-current displacement measurements in machinery protection systems.

The stainless steel armor (Option 01) provides mechanical shielding against physical damage, abrasion, and aggressive industrial environments, unlike standard unarmored configurations. This configuration utilizes a 75 Ohm triaxial FEP-insulated design and corrosion-resistant, gold-plated ClickLoc connectors to maintain signal integrity over the entire 8.5-meter length.

Features

  • 8.5-meter cable length (Option 085) for long-distance sensor connections.
  • Integrated flexible stainless steel armor (Option 01) with FEP outer jacket.
  • Gold-plated ClickLoc connectors that require finger-tight installation only.
  • 75 Ohm triaxial design with fluorinated ethylene propylene (FEP) insulation.
  • CableLoc design providing high strain relief and connection durability.

Applications

  • Steam and gas turbine shaft vibration and axial position monitoring.
  • Centrifugal compressor casing and shaft alignment measurements.
  • Industrial gearbox, fan, and pump machinery protection systems.
  • Heavy machinery monitoring in environments requiring rugged armored cabling.

Ordering Information

Option Code on This SKU Description
Orderable Part Number 330130-085-01-00 3300 XL standard extension cable, armored
A - Cable Length Option 085 8.5 meters (27.9 feet)
B - Connector Protector and Cable Option 01 Armored cable
C - Agency Approval Option 00 Not required

Technical Specifications

Manufacturer Bently Nevada
Part Number 330130-085-01-00
Series 3300 XL 8 mm Proximity Transducer System
Cable Length 8.5 meters (27.9 feet)
Cable Material 75 Ohm triaxial FEP-insulated probe cable
Armor Material Flexible AISI 302 or 304 stainless steel (SST) with FEP outer jacket
Nominal Core DC Resistance (R_core) 1.87 ohms +/- 0.28 ohms
Nominal Jacket DC Resistance (R_jacket) 0.56 ohms +/- 0.11 ohms
Capacitance 69.9 pF/m (21.3 pF/ft) typical
Connector Type Gold-plated coaxial ClickLoc connectors
Maximum Connector Torque 0.565 N-m (5 in-lbf)
Minimum Cable Bend Radius 25.4 mm (1.0 in)
Operating Temperature -52 to +177 degC (-62 to +350 degF)
Storage Temperature -52 to +177 degC (-62 to +350 degF)
Weight 0.88 kg
Dimensions 250 mm x 250 mm x 40 mm (H x W x D)

Installation Guidelines

To ensure proper signal performance and connection longevity, observe the following engineering guidelines during installation:

  • Always maintain the minimum cable bend radius of 25.4 mm (1.0 in) to prevent internal coaxial damage.
  • Ensure that the sum of the probe length and extension cable length matches the designated total system length of the Proximitor Sensor (e.g., a 9.0 m Proximitor requires a 0.5 m probe and an 8.5 m extension cable).
  • Connectors should be tightened finger-tight until they click. Do not use tools on gold ClickLoc connectors unless mating to a non-XL stainless steel connector.
  • Ensure the armored FEP jacket is routed away from sharp structural edges and high-voltage power lines to minimize mechanical wear and electrical noise.

Compliance and Certifications

This specific variant (Option 00) is intended for applications where hazardous area approvals are not required. For certified installations, please specify Option 05 (CSA, ATEX, IECEx approvals).

Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
Che cosa indica l’opzione 01 per il cavo di prolunga 330130-085-01-00?
L’opzione 01 specifica un’armatura flessibile in acciaio inossidabile (SST) con una guaina esterna protettiva in FEP sopra il cavo triassiale standard, offrendo una robusta protezione fisica in ambienti industriali difficili.
Qual è la lunghezza di questo specifico cavo di prolunga Bently Nevada?
Il cavo ha una lunghezza totale di 8,5 metri (circa 27,9 piedi), come indicato dal codice opzione della lunghezza del cavo 085.
Quali sensori di prossimità sono compatibili con questo cavo di prolunga?
Il modello 330130-085-01-00 è compatibile con la sonda di prossimità Bently Nevada 3300 XL da 8 mm e con la serie di sensori Proximitor.
Qual è la resistenza elettrica di questo cavo da 8,5 metri?
Il cavo ha una resistenza nominale in corrente continua del conduttore centrale (R_core) di 1,87 ohm (+/- 0,28 ohm) e una resistenza in corrente continua della guaina (R_jacket) di 0,56 ohm (+/- 0,11 ohm).
Questa configurazione del cavo include certificazioni per aree pericolose?
No, il codice opzione 00 indica che per questa specifica configurazione non sono richieste approvazioni degli enti certificatori né certificazioni per aree pericolose.
