The 330130-085-01-05 3300 XL extension cable from Bently Nevada supports high-accuracy vibration and proximity monitoring systems used in turbines, compressors, pumps, and critical rotating machinery. This armored extension cable operates as part of the 3300 XL transducer system and provides stable signal transmission between the proximity probe and Proximitor sensor. Power generation plants, refinery facilities, LNG terminals, and petrochemical sites commonly install this cable in high-vibration industrial environments where signal integrity directly affects machine protection reliability.
The armored construction improves resistance against mechanical damage, oil exposure, and cable tray abrasion. The multiple approval configuration supports installation in hazardous industrial areas that require international certification compliance. The 8.5 m cable length allows flexible routing inside turbine enclosures, compressor skids, and machinery cabinets while maintaining proper electrical characteristics for the 3300 XL monitoring system.
| Code Segment | Description |
|---|---|
| 330130 | 3300 XL Extension Cable Series |
| 085 | 8.5 m cable length |
| 01 | Armored cable configuration |
| 05 | Multiple approvals option |
| Parameter | Value |
|---|---|
| Model | 330130-085-01-05 |
| Brand | Bently Nevada |
| Product Type | 3300 XL Extension Cable |
| Origin | USA |
| Cable Length | 8.5 m |
| Cable Type | Armored |
| Agency Approval | Multiple Approvals |
| Weight | 34 g/m |
| Shipping Weight | 1 kg |
| Operating Temp | -52 to 177 deg C |
| Connector Type | ClickLoc coaxial connectors |
| System Compatibility | 3300 XL 8 mm Proximity System |
| Jacket Material | Fluoroethylene propylene |
| Shielding | Factory shielded coaxial construction |
| Power Consumption | Passive device |
Can this extension cable operate with older 3300 monitoring systems?
The cable supports 3300 XL proximity systems directly. Compatibility with legacy 3300 systems depends on probe and Proximitor configuration.
Why does the armored version improve reliability?
The armored structure protects the cable from crushing, abrasion, vibration stress, and accidental mechanical impact in industrial installations.
Can the cable length affect proximity probe calibration?
Yes. Bently Nevada proximity systems require matched electrical lengths between the probe, extension cable, and Proximitor sensor for accurate measurements.
Is the 05 approval option suitable for hazardous locations?
Yes. The multiple approval option supports installations requiring international hazardous area certifications.
Install the extension cable separately from high-voltage motor cables to reduce electromagnetic interference. Maintain proper grounding practices at the monitoring cabinet to improve signal stability.
Avoid excessive bending near connector assemblies during installation. Tight bend radius conditions may affect long-term shielding integrity and connector performance.
Use proper cable clamps inside turbine and compressor skids to minimize vibration transfer into the connector interface. High-vibration environments require stable mechanical support for reliable monitoring operation.
