330730-040-00-05 specifies this 3300 XL 11 mm extension cable configuration with a 4.0 meter length, standard unarmored construction, and multiple hazardous area agency approvals. It connects a 3300 XL 11 mm proximity probe to a 3300 XL Proximitor sensor. When added together, the probe length and extension cable length must match the Proximitor sensor total system length (typically 5.0 meters or 9.0 meters) to ensure accurate, non-contact eddy-current displacement measurements.
Unlike variants with stainless steel armor (Option 01) or FluidLoc fluid-barrier cable jackets (Option 10), this option uses a standard unarmored fluoroethylene propylene (FEP) coaxial cable jacket. The multiple approvals option (Option 05) provides hazardous area certifications for intrinsically safe and non-incendive installations.
| Option Segment | Code Value on This SKU | Configuration Meaning |
|---|---|---|
| Base Model | 330730 | 3300 XL 11 mm Extension Cable |
| A - Cable Length Option | 040 | 4.0 meters (13.1 feet) |
| B - Connector and Cable Option | 00 | Standard cable (unarmored FEP coaxial jacket) |
| C - Agency Approval Option | 05 | Multiple Approvals (including CSA, ATEX, IECEx, etc.) |
| Manufacturer | Bently Nevada (Baker Hughes) |
| Part Number / Model | 330730-040-00-05 |
| Cable Type | 75 Ohm triaxial, fluoroethylene propylene (FEP) insulated coaxial cable |
| Cable Length | 4.0 meters (13.1 feet) |
| Armor Option | None (unarmored) |
| Connector Type | Gold-plated brass miniature coaxial ClickLoc connectors |
| DC Resistance (Jacket) | 1.0 +/- 0.25 ohms (coaxial conductor to coaxial conductor) |
| DC Resistance (Core) | 0.3 +/- 0.1 ohms (center conductor to center conductor) |
| Capacitance | 69.9 pF/m (21.3 pF/ft) typical |
| Minimum Bend Radius | 25.4 mm (1.0 in) |
| Tensile Strength (Max Rated) | 270 N (60 lb) at probe lead to extension cable connectors |
| Operating / Storage Temperature | -52 degC to +177 degC (-62 degF to +351 degF) |
| Relative Humidity | 100% condensing, non-submersible when connectors are protected |
| System Compatibility | 3300 XL 11 mm Transducer System (probes and Proximitor sensors) |
| Connector Component | Connection Interface Type |
|---|---|
| Probe Connection End | Miniature coaxial female ClickLoc connector |
| Proximitor Sensor End | Miniature coaxial male ClickLoc connector |
| Connector Material | Gold-plated brass |
Maintain the minimum bend radius of 25.4 mm (1.0 in) during routing to prevent coaxial core damage. Ensure that the probe-to-extension cable connections are tightened finger-tight, up to a maximum recommended connector torque of 0.565 N-m (5 in-lb). Coaxial connectors must be dry and free of oil or contaminants before assembly. Use of connector protectors or silicone self-coupling tape is recommended for environments exposed to moisture or liquid contaminants, but silicone tape is not recommended in turbine oil environments.
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 330730-040-00-05
Country of origin:United States
Product Type: 3300 XL 11 mm Extension Cable
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 180g
Dimensions: 50 mm x 100 mm x 100 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months
330730-040-00-05 specifies this 3300 XL 11 mm extension cable configuration with a 4.0 meter length, standard unarmored construction, and multiple hazardous area agency approvals. It connects a 3300 XL 11 mm proximity probe to a 3300 XL Proximitor sensor. When added together, the probe length and extension cable length must match the Proximitor sensor total system length (typically 5.0 meters or 9.0 meters) to ensure accurate, non-contact eddy-current displacement measurements.
Unlike variants with stainless steel armor (Option 01) or FluidLoc fluid-barrier cable jackets (Option 10), this option uses a standard unarmored fluoroethylene propylene (FEP) coaxial cable jacket. The multiple approvals option (Option 05) provides hazardous area certifications for intrinsically safe and non-incendive installations.
| Option Segment | Code Value on This SKU | Configuration Meaning |
|---|---|---|
| Base Model | 330730 | 3300 XL 11 mm Extension Cable |
| A - Cable Length Option | 040 | 4.0 meters (13.1 feet) |
| B - Connector and Cable Option | 00 | Standard cable (unarmored FEP coaxial jacket) |
| C - Agency Approval Option | 05 | Multiple Approvals (including CSA, ATEX, IECEx, etc.) |
| Manufacturer | Bently Nevada (Baker Hughes) |
| Part Number / Model | 330730-040-00-05 |
| Cable Type | 75 Ohm triaxial, fluoroethylene propylene (FEP) insulated coaxial cable |
| Cable Length | 4.0 meters (13.1 feet) |
| Armor Option | None (unarmored) |
| Connector Type | Gold-plated brass miniature coaxial ClickLoc connectors |
| DC Resistance (Jacket) | 1.0 +/- 0.25 ohms (coaxial conductor to coaxial conductor) |
| DC Resistance (Core) | 0.3 +/- 0.1 ohms (center conductor to center conductor) |
| Capacitance | 69.9 pF/m (21.3 pF/ft) typical |
| Minimum Bend Radius | 25.4 mm (1.0 in) |
| Tensile Strength (Max Rated) | 270 N (60 lb) at probe lead to extension cable connectors |
| Operating / Storage Temperature | -52 degC to +177 degC (-62 degF to +351 degF) |
| Relative Humidity | 100% condensing, non-submersible when connectors are protected |
| System Compatibility | 3300 XL 11 mm Transducer System (probes and Proximitor sensors) |
| Connector Component | Connection Interface Type |
|---|---|
| Probe Connection End | Miniature coaxial female ClickLoc connector |
| Proximitor Sensor End | Miniature coaxial male ClickLoc connector |
| Connector Material | Gold-plated brass |
Maintain the minimum bend radius of 25.4 mm (1.0 in) during routing to prevent coaxial core damage. Ensure that the probe-to-extension cable connections are tightened finger-tight, up to a maximum recommended connector torque of 0.565 N-m (5 in-lb). Coaxial connectors must be dry and free of oil or contaminants before assembly. Use of connector protectors or silicone self-coupling tape is recommended for environments exposed to moisture or liquid contaminants, but silicone tape is not recommended in turbine oil environments.
