Option 00 (0.0 in unthreaded length) and Option 90 (9.0 in case length) specify this 1/4-28 UNF threaded proximity probe configuration — 330901-00-90-05-02-00. This non-armored 3300 NSv proximity probe is engineered for non-contact eddy-current displacement measurements in tight clearances and reduced target areas. It features a 0.5 meter (20 in) total probe length terminated in a miniature coaxial ClickLoc connector on a standard cable (Option 02), with no agency approval package (Option 00) selected.
The 3300 NSv system is optimized for machinery with small target geometry, such as aeroderivative gas turbines and centrifugal turbocompressors, where standard 5 mm or 8 mm probes cannot fit or would experience severe side-view interference. The probe pairs directly with the 330930 series extension cable and a 330980 Proximitor sensor to provide a linear range of 1.5 mm (60 mils) and a nominal scale factor of 7.87 V/mm (200 mV/mil) over a smaller target footprint.
| Option | Code on This SKU | Description |
|---|---|---|
| Orderable Part Number | 330901-00-90-05-02-00 | 3300 NSv proximity probe, 1/4-28 UNF thread, without armor |
| A - Unthreaded Length | 00 | 0.0 in unthreaded length |
| B - Overall Case Length | 90 | 9.0 in overall case length |
| C - Total Length | 05 | 0.5 meter (20 in) total length |
| D - Connector/Cable Option | 02 | Miniature coaxial ClickLoc connector, standard cable |
| E - Agency Approval Option | 00 | Not required |
| Manufacturer | Bently Nevada |
| Part Number/Model | 330901-00-90-05-02-00 |
| Transducer Family | 3300 NSv (Near Side-View) |
| Thread Type | 1/4-28 UNF-2A thread |
| Armor Option | Without armor |
| Unthreaded Length | 0.0 in (0 mm) |
| Case Length | 9.0 in (228.6 mm) |
| Total Length | 0.5 meter (20 in) |
| Connector Type | Miniature male coaxial ClickLoc connector |
| Cable Type | 75 ohm coaxial, FEP (fluoroethylene propylene) insulated |
| Linear Range | 1.5 mm (60 mils), begins at approx 0.25 mm (10 mils) from target |
| Recommended Gap Setting | 1.0 mm (40 mils) |
| Incremental Scale Factor (ISF) | 7.87 V/mm (200 mV/mil) |
| Deviation from Best Fit Straight Line (DSL) | Less than +/-0.06 mm (+/-2.3 mils) over linear range |
| System Frequency Response | 0 to 10 kHz: +0, -3 dB (with typical system configurations) |
| Probe Tip Material | Polyphenylene sulfide (PPS) |
| Probe Case Material | AISI 304 stainless steel (SST) |
| Tensile Strength | 220 N (50 lb) max rated case-to-lead / connector-to-connector |
| Operating/Storage Temperature | -52 degC to +177 degC (-62 degF to +351 degF) |
| Pressure Sealing | Viton O-ring pressure seal |
| Humidity | 100% condensing, non-submersible (when connectors are protected) |
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 330901-00-90-05-02-00
Country of origin:United States
Product Type: 3300 NSv Proximity Probes
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 120g
Dimensions: 45 mm x 90 mm x 90 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months
