Description

The 330903-00-06-10-02-05 3300 XL NSv proximity probe is a precision-engineered sensor designed for vibration and position measurement in small-bore machinery where standard probes are physically incompatible. This configuration features a 0.6 in case length (Option 06) with 0.0 in unthreaded length (Option 00), paired with a 1.0 m total length cable (Option 10). The probe utilizes the Miniature ClickLoc connector (Option 02) and meets CSA, ATEX, and IECEx hazardous area certification standards (Option 05).

Engineered for the 3300 XL NSv Transducer System, this probe effectively monitors high-speed equipment, aeroderivative turbines, and machines with limited target geometry. The NSv system provides high sensitivity and linearity for small targets, maintaining accurate performance in environments with restricted clearance. This unit is fully compatible with the 330980 Proximitor sensor and 330930 extension cable, ensuring a matched impedance and accurate displacement signal output.

Features

• Option 00: 0.0 in unthreaded length for flush-mount installation flexibility
• Option 06: 0.6 in case length designed for tight-clearance mounting
• Option 10: 1.0 m total system length for standard machine configurations
• Option 02: Miniature ClickLoc connector for secure and reliable cabling
• Option 05: Agency approvals including CSA, ATEX, and IECEx for hazardous area compliance
• Small-view (NSv) sensor tip design optimized for limited target area geometry
• Compatible with Bently Nevada 3300 XL NSv Proximitor sensors and extension cables

Applications

• Small-bore machinery and high-speed equipment monitoring
• Aeroderivative gas turbine vibration measurement
• Axial position and shaft radial vibration monitoring
• Applications with limited target area or restricted space

Ordering Information

Technical Specifications

Installation Guidelines

• Ensure the probe tip is installed in a rigid, non-conductive, or properly grounded bracket to prevent false readings.
• Maintain the specified probe gap as defined by the 3300 XL NSv system calibration for linear operation.
• Avoid sharp bends in the probe lead; adhere to the minimum bend radius requirements for standard coaxial cabling.
• Ensure the Miniature ClickLoc connector is clean and free of contaminants before mating to prevent signal attenuation.
• In hazardous areas, ensure the installation complies with local safety standards and the specific requirements listed on the device tag.

Compliance and Certifications

• CSA (Canadian Standards Association)
• ATEX (Atmospheres Explosibles)
• IECEx (International Electrotechnical Commission System for Certification to Standards Relating to Equipment for Use in Explosive Atmospheres)
