330904-00-25-50-02-00: 3300 XL NSv proximity probe, M8x1 thread with stainless steel armor, 0.0 in unthreaded length (Option 00), 2.5 in case length (Option 25), and 5.0 m total length (Option 50). This probe is a critical component of the Bently Nevada 3300 XL NSv transducer system, specifically used for measuring shaft vibration and axial position in machinery where standard 3300 XL probes are not suitable due to target size or clearance limitations.
The system utilizes a 75 ohm coaxial cable path, which is defined by the Option 02 configuration (Miniature coaxial ClickLoc connector, standard cable). This specific unit is designed for use in environments where agency approvals are not required (Option 00). The 3300 XL NSv system is optimized for small-bore machinery and high-speed equipment where the target geometry requires a smaller probe tip and reduced linear range compared to conventional 8 mm proximity transducer systems.
The 3300 XL NSv proximity transducer system is used for monitoring vibration and position on:
| Option | Code on This SKU | Description |
|---|---|---|
| Orderable Part Number | 330904-00-25-50-02-00 | 3300 XL NSv Proximity Probe, M8x1 thread, with armor |
| A - Unthreaded Length | 00 | 0.0 in |
| B - Case Length | 25 | 2.5 in |
| C - Total Length | 50 | 5.0 m |
| D - Connector/Cable | 02 | Miniature coaxial ClickLoc connector, standard cable |
| E - Agency Approval | 00 | Not required |
| Manufacturer | Bently Nevada |
| Part Number | 330904-00-25-50-02-00 |
| Probe Type | 3300 XL NSv Proximity Probe |
| Thread Size | M8x1 |
| Armor | Stainless steel armor included |
| Linear Range | 1.5 mm |
| Recommended Gap Setting | 1.0 mm |
| Output Sensitivity | 7.87 V/mm (200 mV/mil) |
| Operating Temperature | -55 degC to +177 degC |
| Cable Impedance | 75 Ohm |
Ensure the probe is installed using the supplied lock nut. The recommended gap setting is 1.0 mm for optimal linear performance. When routing the cable, avoid sharp bends that exceed the minimum bend radius. Ensure all connectors are kept clean and free from moisture; use connector protectors if the application environment warrants additional environmental isolation. Probes must be grounded according to local safety standards, typically through the mounting bracket or specified grounding paths.
This configuration (Option 00) does not require specific hazardous area approvals. For hazardous area applications, ensure the correct approval option code is selected according to the site requirements and Bently Nevada documentation.
Global Express Shipping
Returns & Warranty
Manufacturer: Bently Nevada
Product No.: 330904-00-25-50-02-00
Country of origin:United States
Product Type: Sonde di prossimità 3300 NSv
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 120g
Dimensions: 45 mm x 90 mm x 90 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months
