Bently Nevada 330905-00-25-05-01-05 3300 XL NSv Proximity Probe

SKU 330905-00-25-05-01-05

Disponibile

12-month warranty
Free returns within 30 days

Manufacturer: Bently Nevada
Product No.: 330905-00-25-05-01-05
Origin United States
Product Type: 3300 NSv Proximity Probes
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 0.12 kg
Dimensions: 45 mm x 90 mm x 90 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months

Product Documentation

Technical Datasheet (PDF) Complete specifications and technical drawings.

Quantità

Call sales Contact

Product Description

Description

The 330905-00-25-05-01-05 is a 3300 XL NSv proximity probe designed for non-contact displacement, radial vibration, and axial position measurement in machinery with restricted installation space. This configuration features a M10x1 thread (Model 330905), 0.0 in unthreaded length (Option 00), a 250 mm case length (Option 25), 0.5 m total length (Option 05), a ClickLoc connector with connector protector and standard cable (Option 01), and Multiple Agency Approvals (Option 05).

The 3300 XL NSv system is engineered for small-bore machinery and applications where standard 3300 XL 8 mm or 5 mm probes cannot be installed due to tight side-view or counter-bore limitations. It serves as a drop-in replacement for legacy 3300 RAM, 3000-series, and 7000-series 190 transducer systems. This probe pairs with the 330980 Proximitor Sensor and 330930 extension cable to form a calibrated measuring chain.

Features

M10x1 thread body without armor
0.0 in unthreaded length for maximum thread engagement flexibility
250 mm case length ideal for deep-bore mounting requirements
Miniature coaxial ClickLoc connector with integrated connector protector for environmental resilience
Standard cable configuration
Multiple Agency Approvals suitable for hazardous area installations
Designed for measuring shafts smaller than 51 mm (2 in) or flat targets smaller than 15 mm (0.6 in)

Applications

Radial vibration and radial position measurements on small-bore machinery
Axial (thrust) position measurements for aeroderivative turbines
Tachometer and zero-speed measurements
Keyphasor signal sensing for high-speed, small-target equipment
Fluid-filmed bearing monitoring in restricted geometries

Ordering Information

Option	Code on This SKU	Description
Orderable Part Number	330905-00-25-05-01-05	3300 XL NSv Proximity Probe
A - Unthreaded Length	00	0.0 in unthreaded
B - Case Length	25	250 mm (25 x 10 mm increment)
C - Total Length	05	0.5 meter (20 in)
D - Connector/Cable	01	Miniature ClickLoc, standard cable, connector protector
E - Agency Approval	05	Multiple Approvals (CSA/ATEX/IECEx)

Technical Specifications

Parameter	Specification
Manufacturer	Bently Nevada (Baker Hughes)
Part Number	330905-00-25-05-01-05
Probe Type	3300 XL NSv Proximity Probe
Thread Size	M10x1
Case Length	250 mm
Unthreaded Length	0.0 in
System Length	0.5 m
Connector Type	Miniature coaxial ClickLoc with protector
Cable Type	Standard
Operating Temperature	-52 degC to +177 degC
Agency Approvals	Multiple (CSA, ATEX, IECEx)

Compliance and Certifications

ATEX/IECEx: Ex ia IIC T5...T1 Ga; Ex ia IIIC T90C...T280C Dc
CSA/NRTL/C: Class I, Zone 0; Class I, Div 1, Groups A, B, C, D
Functional Safety: SIL 2 (HFT=0) / SIL 3 (HFT=1)
EMC: Directive 2014/30/EU, EN 61000-6-2, EN 61000-6-4
RoHS: Directive 2011/65/EU

Shipping & Returns

Global Express Shipping

Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
12-Month Warranty: Every industrial component is backed by our technical warranty.

FAQ

Che cosa significa l'opzione 00 per la lunghezza non filettata di questa sonda?

L'opzione 00 indica una lunghezza non filettata di 0,0 pollici; ciò significa che la filettatura della sonda inizia immediatamente dietro la punta, consentendo il massimo innesto della filettatura nel foro di montaggio.

Questa sonda è compatibile con i sensori Proximitor standard 3300 XL da 8 mm?

No, questa è una sonda NSv (non standard). Deve essere utilizzata con il sensore Proximitor NSv 330980 specifico e il cavo di prolunga NSv 330930 per garantire una corretta calibrazione e un funzionamento corretto del sistema.

Qual è lo scopo del connettore di protezione (opzione 01)?

Il connettore di protezione garantisce la tenuta ambientale nel punto di giunzione tra la sonda e il cavo di prolunga, proteggendo da contaminanti come umidità, olio o polvere, un aspetto fondamentale per l'affidabilità a lungo termine nelle applicazioni industriali.

Questo modello di sonda richiede specifiche omologazioni per l'installazione?

Sì, l'opzione 05 indica che questa unità è certificata con diverse omologazioni, tra cui CSA, ATEX e IECEx, e che è quindi adatta alle installazioni in aree pericolose in cui sono richieste queste certificazioni specifiche.
